Disc Separator
HongVadar has all kinds of engineering and technical personnel with more than 30 people, including 8 senior designers, who had serviced for the international famous enterprise like Cargill, DA CHENG GROUP, and a number of well-known domestic and design institute; who has also played in MEIHUA GROUP, EPPEN, Yihai Kerry and other international well-known fermentation enterprise and who has also played in the American Komline-Sanderson company. HongVadar has rich engineering, equipment supply, and production experience in starch, all kinds of sugar , and ethanol production line.
In the starch separation process, HVD-SP-P series high speed starch disc separator produces very high centrifugal force due to high speed rotation, which improves the separation machine efficiency and maximizes the production efficiency. High speed starch disc separator has the advantages of all kinds of separator, small vibration, large handling capacity and stable operation. It is mainly used in pre-concentration of starch, separation of starch and gluten, concentration of gluten (protein) and clarification of water in the process.
Disc Separator Features
- Large rotary drum diameter, large disc area, strong processing (separation) ability, good separation effect:
- Automatic control of lubricating oil circuit is adopted to protect the driving system and extend the service life of the driving system;
- Large nozzle is adopted to ensure the continuity of production with large feeding capacity and small blocking opportunity:
- Equipped with a drum lifting hydraulic system, which makes high speed separator more convenient to overhaul the drum and replace the nozzle;
- The drum is made of imported high-strength corrosion-resistant stainless steel, which ensures the safety and stable operation of the high speed starch disc separator ;
- The high speed starch disc separator can be started without load;
- Can handle materials of various concentrations without internal adjustment;
- The high speed starch disc separator has an internal circulation system to keep the separation stable and facilitate accurate adjustment and control.
- Simple operation, operators can quickly master the operating procedures.
Disc Seperator Technical Parameters
Model
|
Capacity (T/H)
|
Drum speed (rpm)
|
Power (Kw)
|
Weight (kg)
|
Overall dimension L×W×H (mm)
|
HVD-SP445-P30
|
20-35
|
4500- 5200
|
30
|
1400
|
1284×1407×1457
|
HVD-SP520-P37
|
25-45
|
4650
|
37
|
1550
|
1617×1240×1565
|
HVD-SP600-P75/55
|
30-60
|
2850- 4800
|
75/55
|
3500
|
2000×1000×2050
|
HVD-SP800-P132/110
|
22-115
|
2750- 3300
|
132/110
|
7800
|
2800×1500×2200
|
HVD-SP935-P250/220
|
45-225
|
2250- 3050
|
250/220
|
11000
|
3200×1800×3100
|
