CP500M/CP500SW
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Parameters and Specification of CP500M Wi-Fi Extender |
||
|
Parameter |
Specification of CP500M Wi-Fi Extender |
|
|
PLC Characteristic |
Standard |
IEEE 1901, HomePlugAV |
|
|
Frequency |
2MHz—68MHz |
|
|
Transmission distance |
300m |
|
|
Power line physical layer rate |
500Mbps |
|
|
Modulation |
OFDM, QAM, DQPSK, DBPSK |
|
|
Encryption mode |
AES-128 |
|
Button and Interface |
1*Reset button, compatible with a pairing function 1*100Mbps Ethernet interface, RJ45 |
|
|
Ethernet Interface Characteristic |
Fully compatible with IEEE802.3/802.3u protocol 10Base-T & 100Base-TX Full/half-duplex mode Auto MDI/MDIX |
|
|
Indicator |
Power: power light LAN: network interface light PLC: link status light |
|
|
Consumption |
< 3W |
|
|
Environmental Parameters |
||
|
Operating Temperature |
0℃—40℃ |
|
|
Storage Temperature |
-20℃—70℃ |
|
|
Operating Humidity |
10%—90%(Non-condensing) |
|
|
Storage Humidity |
5%—95%(Non-condensing) |
|
|
Power |
100VAC~240 V AC, 0.15A, 50/60Hz |
|
|
Physical Characteristic |
||
|
Dimension |
L x W x H: 70mm x 70mm x 38mm |
|
|
Weight |
60 g |
|
|
Parameter |
Specification of CP500M Wi-Fi Extender |
|
|
PLC Characteristic |
Standard |
IEEE 1901, HomePlugAV |
|
|
Frequency |
2MHz—68MHz |
|
|
Transmission distance |
300m |
|
|
Power line physical layer rate |
500Mbps |
|
|
Modulation |
OFDM, QAM, DQPSK, DBPSK |
|
|
Encryption mode |
AES-128 |
|
Wi-Fi Characteristic |
Standard |
IEEE802.11b/g/n |
|
= |
Frequency |
2.4GHz |
|
= |
Wireless data rate |
300Mbps |
|
= |
Transmission distance |
100m indoor environment 300m outdoor open environment |
|
= |
Encryption mode |
WPA-PSK、WPA2-PSK |
|
Button and Interface |
1*Reset button, compatible with a pairing function 1*100Mbps Ethernet interface, RJ45 |
|
|
Ethernet Interface Characteristic |
Fully compatible with IEEE802.3/802.3u protocol 10Base-T & 100Base-TX Full/half-duplex mode Auto MDI/MDIX |
|
|
Indicator |
Power: power light WiFi: WiFi light PLC: link status light |
|
|
Consumption |
＜5W |
|
|
Environmental Parameters |
||
|
Operating Temperature |
0℃—40℃ |
|
|
Storage Temperature |
-20℃—70℃ |
|
|
Operating Humidity |
10%—90%(Non-condensing) |
|
|
Storage Humidity |
5%—95%(Non-condensing) |
|
|
Power |
100VAC~240 V AC, 0.15A, 50/60Hz |
|
|
Physical Characteristic |
||
|
Dimension |
L x W x H: 70mm x 70mm x 38mm |
|
|
Weight |
120 g |
|
As a reliable wireless network manufacturer, we provide 300mbps av200 wifi powerline extender starter kit, kit powerline wireless, extend wifi through power lines, av200 wifi powerline extender, 300mbps av600 wifi powerline extender and etc. Want to know more. Contact us, we will try our best to meet the needs of all customers.
