UL LED panel light

Description:

· Unique design of Light Guide Panel - gives good performance of lighting

· High-quality of branded chip - provide excellent lumens

· Detail assurance - bring reliable trust to our clients worldwide

Key words: UL LED panel light, DLC LED panel lighting, 2x2 LED panel, LED ceiling panel light

Brand: ILUBOX

Installation: Recessed, Suspended, Mounted,

Lighting: Side lighting

Application: Meeting Room, Hotel, Office, House, School, Institution, Factory, Warehouse, Hospital etc..

Net/Gross Weight: 4.2kg/5.5kg (PC)

Gross Weight: 8.45kg/CTN

Packing Information: 2pcs/CTN, CTN: 630*635*90mm

Panel: L=604mm W=604mm H=60mm Driver Box=50x100x320mm

Panel: L=23.8" W=23.8" H=2.36" Driver Box=1.96"x3.94"x12.6"

Characteristics: High lumen

Advantages: ILUBOX wanna supply not only good products, but also incredible experience.

Specification:

Model No.: ILU-105-UL22-50

UL Model Number: ET-22-52W

Power: 50W±2W

Power supply: 100~277Vac 50/60Hz

Driver Output Data: 25-38Vdc/1400ma/45W

Power Factor/THD/PE: >90%/<20/88%</p>

Driver: Fixed Driver

Over Load/Short Circuit: Protection

Surge/Protection Class IEC: >1KV/ClassII

Hi-pot Test Range: SELV Isolated Driver, 3750Vdc/5mA/60S

Total delivered lumens: 5250LM

Colour temperature: NW 3000K NW 4000K CW 5500K/6000K

CRI / SDCW: >80 / <6</p>

Dimension(MM): 604*604*11mm

Type of LED: 26x46mil Chip/192pcs

Light Guide Panel brand: Japan Mitsubishi

Material: Aluminum

Beam Angle: 120°

LumenMaintenance70%: 100,000hrs

LM80: >97.1% lumen maintance @ 6,000hrs

Dimmable: 0~10V(UL)/Dali/PWM/Traic Optional

Frame Color RAL: Pure white/RAL9016

Power supply unit: external driver

IP/IK/Glow-wire: IP20/IK06/650℃

Temp./Humidity: Working: -20℃~40℃ Storage: <60℃/<75%</p>

Warranty: 6 years
