Laser engraver machine |
|
|
CE&RoHS Compliance |
| All LP products are RoHS-compliant (the European Parliament Directive 2002/ 95/ EC, Restriction of Hazardous Substances) and lead-free (pb free). LP will continue to concern and provide environmentally friendly products to protect the earth for our further generation. |
| Drag-N-Play |
|
| The "Drag-N-Play" feature greatly reduces complex set up procedures and allows users to directly drag the lens carriage to the starting point of a job. |
|
|
SmartPIN™ AutoFocus (Patented) |
| The plug and play probe design makes focusing a one-touch process and provides the accuracy and precision required for optimum quality even on transparent materials |
| Easy to Use Control Panel |
|
| A control panel with coherent hot-key design and graphical icon displays that allows you to change laser parameter settings, set jobs to repeat unlimited times, queue jobs, delete jobs, and more. |
 |
Key Switch Emergency Stop |
| Key switch safeguards the machine from unauthorized use.Prominent emergency button located on the top of the machine allows operators to stop the laser and the motion carriage immediately to provide a safe operating environment. |
Specs
| Model | LP-13 |
| Working Area | 1300*900mm |
| Laser Power | 80W/100W/130W/150W |
| Laser Type | CO2 Sealed Laser Tube, 10.6μm |
| Cooling Type | Water Cooling |
| Engraving Speed | 0-60000mm/min |
| Cutting Speed | 0-40000mm/min |
| Laser Output Control | (0-100% Set by Software ) |
| Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm |
| Highest Scanning Precision | 4000DPI |
| Locating Precision | ≤+0.01mm |
| Controlling Software | DSP Control System |
| Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc |
| Compatible Software | TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,etc |
| Color Separation | Yes |
| Drive System | High-precision 3-phase Stepper Motor |
| Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe |
| power Supply | AC110V/220V+10%,50HZ/60HZ |
| Working Environment | Temperature: 0-45℃,Humidity 5-95%(No Condensate Water) |
| Optional Spare Parts | Honeycomb Worktable, Rotary Device,Auto-focus Device |
Materials
|
Material |
 |
 |
 |
| Acrylic | √ | √ | × |
| Glass | √ | × | × |
| Laminates | √ | √ | × |
| Leather | √ | √ | × |
| Metal | × | × | × |
| Paper | √ | √ | × |
| Plastics | √ | √ | × |
| Stone | √ | × | × |
| Textiles | √ | √ | × |
| Wood | √ | √ | × |
Showcase
|
Stone |
Bamboo |
Plastic |
Wood |
