Products

As a professional custom gear manufacturer, Laifual has developed a wide range of harmonic gearbox series, including LSS, LSG, LSN, LSD, LFS, LHT, etc., covering standard type, large diameter, thin, shorten harmonic gearbox.

Laifual Harmonic Gearbox & Planetary Gearbox

Laifual prides itself on delivering innovative solutions for our customers in varying industry sectors, applications, and locations all over the world. Our gearbox products are aimed at providing optimal performance solutions for industry partners.

Harmonic Gearbox

LSS/LSG/LSN Standard Type/High Torque/Light Weight Harmonic Gearbox

Laifual adopts our newest developed 'LS' tooth profile, which improves harmonic reducer's comprehensive performance a lot.

LSD Shorten Thin Harmonic Gearbox

LSD series is a newly developed strain wave gear/drive based on the LSS series to fulfil the needs of the current market.

LFS Ultra Flat Harmonic Gearbox

LFS series-this harmonic actuator is a combination product that is lightweight and ultra-flat. It uses cross-roller bearing.

LHT/LHN/LHG Large Diameter Hollow Hole, Flat Shape Harmonic Gearbox

LHT Series use hat type flexspline. We can divide LHT series into 5 versions, LHT-I, LHT-II,LHT-III,LHT-IV and LHT-V.

LHD Shorten Thin Harmonic Gearbox

LHD series's flex spline is a flanging ultra-short tube structure.

Function of Gear box

LFB Concentric Shaft Planetary Gearbox

Powerful tool in precision positioning with a backlash of less than 0°03'.

LFF Flange Output Planetary Gearbox

Output flange and tapered roller bearings for high load capacity.

LFD Planetary Gearbox

VRS Series; Tapered roller bearings for high load capacity.

LFE Planetary Gear Speed Reducer

VRL Series; Powerful tool in precision positioning with a backlash of less than 0°05'.

LFBR Right-angle Series Planetary Gearbox

A high-performance right-angle solution for servo applications that keeps LFBR's design and characteristics.

LFFR Right-angle Series Planetary Gearbox

A high-performance right-angle solution for servo applications that keeps LFFR's design and characteristics.

LFER Right-angle Series Planetary Gearbox

A high-performance right-angle solution for servo applications that keeps LFER's design and characteristics.

LFA Planetary Gearbox

Powerful tool in precision positioning with a backlash of less than 0°03' Reduction Ratio: 1/3-1/100 Backlash: 0.05° (within 3 min)

LFAR Right-angle Series Planetary Gearbox

A high-performance right-angle solution for servo applications that keeps LFAR's design and characteristics.

How does a Harmonic Drive Work?

The rotation movement comes from the input shaft, which can be a servo motor shaft. This is connected to an element called "harmonic wave generator", which has an elliptical shape and is surrounded by an elliptical ball bearing. When the axis rotates, the edge changes position, so it looks like a motion wave is being generated. The part is inserted into a flexible spline made of torsionally rigid but flexible material. The material absorbs this fluctuation by bending and forming an ellipse according to the rotation of the input shaft. The outer edge of this flexible spline has gear teeth suitable for transmitting high loads without any problems. In order to transmit these loads, the flexspline is installed in a circular spline, which is a circular gear with internal teeth. The outer ring is rigid, and its inner diameter is slightly larger than the main axis of the ellipse formed by the flexspline. This means that the circular spline does not assume the elliptical shape of the other two components, but simply meshes its inner teeth with the teeth on the outer flexspline, causing the flexspline to rotate.

The speed depends on the speed of the input shaft and the difference in the number of teeth between the flexspline and the circular spline. The number of teeth of the flexspline is less than that of the circular spline, so it can rotate in the opposite direction at a smaller rate than the input shaft. The reduction ratio is: (the number of flexspline teeth-the number of circular spline teeth)/the number of flexspline teeth. The difference in the number of teeth can be changed to adapt to different reduction ratios, thereby adapting to different professional needs and requirements.

Applied Industries Of Harmonic & Planetary Gearbox

Laifual Designs And Manufactures Harmonic Gearbox And Planetary Gearbox For All The Industrial Areas With Competence, Innovation, And Unique Professionalism. As One Of The Mature Gearbox Companies In China, Laifual Exceeds Customer Expectations With The Highest Level Of Detailed Engineering, Lean Manufacturing, And Quality Assurance Available In The Global Marketplace. Modularity, Accuracy, And Performance Will Allow You To Select From The Laifual Range. The Product Can Best Suit Your Application And Optimize Overall Design Costs. Laifual's Products Are Widely Used On Robots, Automation Equipment (cnc Equipment, Rotation Equipment), Medical Equipment, Aerospace And Etc.

We provide different types of gear box, such as reduction drive gearbox, drive gearbox, gear reduction drive box, etc.
