1.5 Inch 4000psi Brass Internal Dry Pressure Gauge With Front Flange
1.5 inch 4000psi high pressure with back connection and front flange installation style, stainless steel case, brass internal and connection.
Specifications:
Specifications of 1.5 Inch 4000psi Brass Internal Dry Gauge With Front Flange
|
Dial |
1.5”,2”,2.5”,3”,4″,6”,8",10"(40mm,50mm,63mm,75mm,100mm,150mm,) 00mm,250mm) |
|
Scale ranges |
-1/600bar |
|
Accuracy class |
1.6%(≤63mm);1.0%(＞63mm) |
|
Process connection |
1⁄4″(63mm),1⁄2″(100 mm or above )NPT or BSP or BSPT |
|
Bourdon tube |
Brass |
|
Wetted parts/socket |
Brass |
|
Movement |
Brass |
|
Pointer |
Aluminum, micrometer adjustable available |
|
Welding |
Sn Welding; Silver alloy Welding for high pressure series |
|
Case material |
Stainless steel 304,DIN bayonet bezel or crimped ring |
|
Window(lens) |
Tempered glass, pc or safety glass |
|
Fill |
Glycerin or silicone |
|
IP class |
IP 65 |
Now the price of front flange pressure gauge is reasonable, if you have needs, please contact us.
As a pressure gauges manufacturer, we can offer different types of pressure gauges for sale, anything you need, please leave us a message.
