21.5 Inch 1920x1080 FHD 30PIN LVDS-Double IPS 600nits Open Frame LCD
Quantité : 500pcs/day Prix : 30USD-300USD
21.5 Inch 1920x1080 FHD 30PIN LVDS-Double IPS 600nits Open Frame LCD
EX21501-A01 is a 21.5 inch 1920×1080 Resolution IPS TFT LCD module that supports LVDS interface. It can be operating at temperatures from 0~50℃ and storage temperatures range from -20~65℃. And, it features with 600(nits) high brightness and wider viewing angle technology. Open frame tft display is Suitable for industrial and medical imaging、 self-service terminals、 retail terminals、 supermarket checkout machines,etc.
General Specifications of 21.5 Inch 1920x1080 FHD 30PIN LVDS-Double IPS 600nits Open Frame
RGB vertical stripe
No. |
Item |
Specification |
1 |
LCD size |
21.5 INCH |
2 |
Resolution |
1920×1080 |
3 |
Active area |
476.64(H)×268.11(V)mm |
4 |
Module size |
487.54(H)×279.684(V)×1.335(D)mm |
5 |
Interface |
LVDS-Double |
6 |
Brightness |
600cd/m2 |
7 |
Contrast Ratio |
4000: 1 |
8 |
Pixel arrangement |
|
9 |
Surface Treatment |
Anti-Glare |
10 |
Display Colors |
16.7M |
11 |
Polarizer |
Transmissive |
12 |
Display mode |
Normally Black |
As a professional tft module factory, we provide tft lcd display module, ips tft capacitive touchscreen, ips capacitive, ips capacitive screen, ips lcd capacitive, ips touch panel, ips capacitive touchscreen, ips lcd touch screen, ips lcd capacitive touchscreen, china tft lcd display, etc. For more information, please feel free to contact us!
Personne à contacter : tech exson, 0755 2101 8006
