280W Monocrystalline Solar Panel
We are a well-known solar products company and we have 12 years of manufacturing experience for solar products, which include the solar module, solar energy system and solar lighting products, passing important tests in various industries like TUV, CE, CQC, FCC, RHOS, ETL, etc..
280W High Efficiency Monocrystalline Solar Panel
260~310W factory direct sale monocrystalline solar panel with competitive price, our customers can not only purchase this panels individually but also purchase a whole set of the solar PV power system, it includes solar panels, battery, controller, inverter and installation material of the system. This solar panel 280w series in Sunworth is of high-quality and it is welcomed by the market.
Advantages of 280W Monocrystalline Solar Panel
- Professional PV products manufacturer.
- Higher photoelectric conversion efficiency than a poly solar panel.
- Personality customized solutions can be provided.
- Passed a variety of harsh environmental tests, like salt spray, ammonia and sand storm corrosion tests.
- Excellent PID resistance performance limited power degradation.
- Suitable 280w solar panel price.
Product Parameters of 280W Monocrystalline Solar Panel
Electrical Parameters
|
Model No. |
SW270M-60 |
SW290M-60 |
SW320M-60 |
|
Max Power |
270W |
290W |
320W |
|
Max Voltage |
30.72 |
31.22 |
32.42V |
|
Max Current |
8.79 |
9.29 |
9.87A |
|
Open-circuit Voltage |
37.45 |
38.52 |
41.15V |
|
Short-circuit Current |
9.57 |
9.85 |
10.34A |
|
Module Efficiency |
16.60% |
17.83% |
19.67% |
|
Operating Temperature |
-40℃~+85℃ |
||
|
Max System Voltage |
1000Vdc |
||
|
Max Series Fuse Rating |
15A |
||
|
Power Tolerance |
±3% |
||
|
*STC condition: 1000 W/m² |
1.5AM and 25℃ cell temperature |
||
Temperature parameters
|
NMOT |
46℃±2℃ |
|
Temperature Co-efficient of Pmax |
-0.398%/℃ |
|
Temperature Co-efficient of Voc |
-0.340%/℃ |
|
Temperature Co-efficient of Isc |
0.0576%/℃ |
Mechanical Parameters
|
Cell size |
156.75*156.75mm |
156.75*156.75mm |
156.75*156.75mm |
|
Cell amounts |
60(6*10) |
60(6*10) |
60(6*10) |
|
Weight |
17.6kg |
17.6kg |
17.6kg |
|
Module Dimension |
992*1640*35mm |
992*1640*35mm |
992*1640*35mm |
|
Front Cover |
3.2mm tempered glass |
||
|
Frame Material |
Anodized aluminium alloy |
||
|
Junction Box |
IP67 rated |
||
|
Output Cables |
4mm2, Length 900mm+MC4 |
||
Packing
|
Power |
270W |
290W |
320W |
|||
|
Packing |
20'GP |
40'HC |
20'GP |
40'HC |
20'GP |
40'HC |
|
Pieces/Carton |
30 |
30 |
30 |
30 |
30 |
30 |
|
Pieces/Container |
360 |
896 |
360 |
896 |
360 |
896 |
