600W 24V 20A Battery Charger
Quantité : 3 Million Prix : 1.2USD - 130USD
Typical output: 24v 20a battery charger
Fully auto 4 stages charging process by MCU controller
4 LED indicate the battery capacity from 25%~100%
Worldwide AC input 100V-240V
Charging stage: Small current pr-charge; constant current charging; Constant voltage charging
The Specifications Of 600W 24v 20 amp battery charger
Charger Model |
AC Input Voltage |
Battery Voltage |
Max Voltage(V) |
Max Current (A) |
|
AP-H/LF600CH01460250 |
110/220 |
12 |
14.6 |
25 |
|
AP-H/LF600CH02920200 |
110/220 |
24 |
29.2 |
20 |
|
AP-H/LF600CH04200150 |
110/220 |
36 |
42 |
15 |
|
AP-H/LF600CH05460120 |
110/220 |
48 |
54.6 |
12 |
|
AP-H/LF600CH07140100 |
110/220 |
60 |
71.4 |
10 |
|
AP-H/LF600CH08400080 |
110/220 |
72 |
84 |
8 |
|
AP-H/LF600CH01200250 |
110/220 |
12 |
14.7 |
25 |
|
AP-H/LF600CH02400200 |
110/220 |
24 |
29.4 |
20 |
|
AP-H/LF600CH03600150 |
110/220 |
36 |
44.1 |
15 |
|
AP-H/LF600CH04800120 |
110/220 |
48 |
58.8 |
12 |
|
AP-H/LF600CH06000100 |
110/220 |
60 |
73.5 |
10 |
|
AP-H/LF600CH07200080 |
110/220 |
72 |
88.2 |
8 |
|
INPUT |
AC Input Voltage Range |
100V ~ 240V |
|||
AC Input Frequency |
45~65HZ |
||||
AC Power Factor Correction |
≥0.98 |
||||
OUTPUT |
Output Voltage Range |
12~60V |
|||
Output Power Range |
15A(Max) |
||||
VIBRATION |
10~50HZ 2G 10 minutes,X,Y,Z /60 minutes |
||||
DIMENSIONS(mm) |
(L)183х(W)122.5х(H)69 |
||||
Protections |
Over current protection ,Over Voltage Protection ,Short- circuit Protection Reverse Connection Protection ,Battery open-circuit protection |
||||
CERTIFICATIONS |
CE ROHS |
||||
PACKING DETAILS |
1.8kg/pcs 12pcs/Carton Carton size: 535*315*280mm |
Shen Zhen Shi Alrightpower Technology Co., Ltd is a professional 12v 20a battery charger supplier, we provide 180w power adapter, industrial power adapter and etc. Want to know more, contact us.
