ACS-M77 Rope making machine
Quantité : 20 per mon Prix : USD10000~50000/set
Performance and Characteristics:
1.Natural or man-made fibre all can be used in this machine for making rope.
2.It can produce coils length from 415-2600m.
3.It can produce or process the three-strand and four-strand ropes.
4.The machine can do twisting into multi-strand and rope making in one time.
5.High production speed , extremely high output.
Main features:
Notice: Our Pay-off shaft can be adjusted into different type in order to suitable for different size and number Pay-off bobbins.
1.Hydraulic tension system
2.Increasing take-up capacity
3.Double-twist per rotary, two for one twisting
4.Constant tension for rewinding system
5.Lightweight rotating arm part
6.Frequency drive
7.PLC and touch-screen control
8.Low noise level
9.It's high-efficient and energy economical.
10.The structure and processing are designed terse ,friendly and can be used flexibly and conveniently with steady and safe in motion.
11.It's CNC control system which can adjust the strand making and rope twisting without stop machine, easy operation.
12.Pre-twist factor and rope twist can be adjusted and synchronized by three-motors under electrical control system.
Main Technical
|
Rope range |
|
10-30mm |
|
|
Flyer speed |
|
0-max.360 rpm, depending on pre-twist factor |
|
|
Rope Lay |
|
S and Z |
|
|
Twists per minute |
|
2 x rope flyer speed |
|
|
Lay Length |
|
45-122mm/22-8.2 twists per meter; |
|
|
Pre-twist factor |
|
0.4-2.0 x rope twist |
|
|
Take-up, coiling head: |
|
Ø 900 mm, adjustable traverse max. 525 mm, barrel Ø260 mm |
|
|
Take-up, max. weight |
|
Polypropylene 170 kg |
|
|
Pay-off packages: |
|
M77/3 |
M77/4 |
|
|
|
3 x 22, max. Ø250 x 300 mm traverse |
4 x 22, max. Ø250 x 300 mm traverse |
