AD145S-P High Shear Lab Mixer
Quantité : 1 Prix : 100,00 €
Laboratory Homogenizers Emulsification Heads Handheld Superfine Homogenizers AD145S-P 6G 0.2-10ml
1. Description of XZBELEC's AD145S-P high shear lab mixer
AD145S-P ultrafine homogenizer is suitable for liquid / liquid mixing, emulsification, homogenization, liquid / solid powder dispersion, tissue cell mashing, slurry and other experiments, which is designed for micro-experimental media processing and design. Products used in bio-pharmaceutical, genetic research, tissue fragmentation, cytoplasm, pathological analysis, dairy homogeneity, polymerization and other experimental areas. Product design novel, advanced technology, with the output power, high speed, easy operation and other characteristics of the experiment. Its unique stepless speed control operation state function, so that equipment in the speed range can choose the experimental run speed, for the experiment to provide a guarantee. Ultra-fine homogenized work head of the unique structure to ensure that the rotor head in the motor drive at high speed with high speed, resulting in a strong liquid shear force and severe high-frequency mechanical effects, to promote the experimental material under the action of great centrifugal force, The experimental medium is subjected to cutting, tearing and mixing up to tens of thousands of times per minute. Its unique characteristics and functions, in fact, the medical units, biological, health and epidemic prevention, cosmetics, food processing, tertiary institutions such as scientific research, product development, quality control and production process application of the ideal equipment.
2. Homogenization Table Selection Table
Specification (G) |
6 |
8 |
10 |
Processing capacity (ml) |
0.2 ~ 10 |
1 ~ 60 |
30 ~ 250 |
Maximum viscosity (mPa.S) |
100 |
100 |
200 |
Maximum linear velocity (m/s) |
8 |
10 |
13 |
Minimum/Maximum immersion liquid length (mm) |
12/60 |
15/85 |
20/110 |
Working head length (mm) |
123 |
148 |
178 |
Maximum temperature (℃) |
120 |
120 |
120 |
Work head Materia(#) |
SS316 |
SS316 |
SS316 |
Bearing material(#) |
PTFE |
PTFE |
PTFE |
3. Technical Parameters
Rated voltage: 220V AC
Rated frequency: 50/60Hz
Input power: 145W
Output power: 110W
Rated torque: 3.1N·cm
Work mode: S1( Continuous)
Operation control method: Speed dial
Speed adjustment range (idle running): 5000-35000rpm
Rotating speed control type: 6 gears
Peak orque of the sirring head: 3.0N.cm
Stirring head material: AISI 316
Stirring head specification: 6G
Adaptable head specification (optional): 10G/8G
Permissible ambient temperature: not more than 40 ℃
Permissible relative humidity: not more than 80 %
Size of the mixer (T x B x H): 380 x 80 x 50mm
Weight: 1.0kg
