AVCiT Phinx-288 Ports Fiber KVM Matrix
AVCiT Phinx-288 Ports Fiber KVM Matrix
AVCiT Fiber KVM Collaboration System (non-IP) is based on distributed and scalable architecture with optional features, which can be configured as a KVM matrix, KVM switch, KVM extender, video wall controller or all of them in same system. By its advanced features and uncompressed image transmission with redundancy features to transmit 4K@60 4: 4: 4 chroma images, the solution is add-value for control room, TOC, AOC in transportation, energy, aviation industries. There are 24 slots for Fiber Optic I/O module or Video Wall Control module by 288 Ports KVM Over Fiber Matrix
Specification of Phinx-288 Ports Fiber KVM Matrix
|
Resolution |
Support 3840x2160@60 and downward compatibility |
|
Image Processing |
Advanced FPGA |
|
Channel Amount |
max. 288 channels by auto-recognize Fiber I/O port |
|
Bandwidth |
up to 12 GB per channel |
|
Communication Port |
RS232 x1, RJ45x1 |
|
Protocol |
SNMP, RS232, UDP |
|
Transmission Distance |
Transmit audio, video, control signals over fiber optic up to 20km. |
|
Power Supply |
110-220V PSU, power redundancy available |
|
Dimension |
481x457x864 mm, racked by standard rack |
Highlights of Phinx-288 Ports Fiber KVM Matrix
Flexible to configure as a KVM matrix, KVM extender or video wall controller.
Highlights of Phinx-288 Ports Fiber KVM Matrix
Fully cross-point matrix switching, Auto-recognizable port for input or output signal
Guangdong AVCiT Technology Holding Co., Ltd(Stock name: AVCiT Technology, Stock Code: 001229) provides Integrated IP Based KVM Solutions and Distributed & Fiber KVM Matrix System for Command & Control Room, with revolutionary technologies which greatly add more value to your Meeting Room and Control Room Design.

Now the price of video wall processor is reasonable, if you have needs, please contact us.
