BCD explosion-proof hoists

1. Introduction of electric wire rope hoist( http://www.electric-block.com/products-e/15.html )

Explosion-proof electric hoist is a kind of small-sized lifting equipment which is small volume,light weight, huge lifting capacity. When workshop filled with explosive mixture, in order to ensure safe premise. Explosion-proof electric hoist is necessary and favorable equipment to improve labor conditions and labor productivity. It can be suspended on I- beam track for straight or curve traversing, or mounted on a fixed frame to lift heavy material.
Main components: explosion proof motor, reducer, wire rope, guide rope, drum, hooks,electircals and so on.
2. Features
High quality wire rope
Easy operating contact sales1 at yiyinggroup dot com
Full certification, competitive price
Food after serv Electric Hoist
Lifting Capacity: 0.25-20t
Lifting Height: 3-30m( Max100m)
Working System: M3, M4
Ambient Temperature: -25~+40°C
Lifting Capacity: 0.25-10t
Working System: M3, M4
Ambient Temperature: -25~+40°C

3. Parameters

Model
BCD 0.5t BCD 1t BCD 2t BCD 3t BCD 5t BCD 10t
Capacity T 0.5 1 2 3 5 10
Lifting speed m/min 8

Lifting height m 6/9/12/18 6/9/12/18/24/30 6/9/12/18/24/30

6/9/12/18/24/30 6/9/12/18/24/30 6/9/12/18/24/30
Running speed m/min 20

Min radius of curvature m 1.8/2 2/2.5/3.0 2/2.5/3 2/2.5/3.0 2/2.5/3.0 2/2.5/3.0

Voltage V 380/ customize

Frequency HZ 50

Phase 3

I beam type
16-28b 16-28b 20a-32c 20a-32c
25a-63c 25a-63c
