Bolts and Screws Rubbertrack Shot Blasting Equipment
Quantité : 100 Prix : Q32
Bolts and screws rubbertrack shot blasting equipment
1.The efficient & rugged design of tumble blasting machine increase production, improves quality and reduces fettling cost,
saves labour, spaces, saves power, cuts tooling costs & reduces rejection.
2.The tumble blasting machine is available with rub conveyor or Steel Conveyor. Rugged one piece cast, hardened and stress relieved chain link gives long life.
3.The Machine is suitable for shot blasting components like valve bodies, Cylinder head, and tractor components. The fast action of shot blasting removes every trace of sand, scale, write down to virgin metal.
4.There by lengthen tool life, speeding up machining, simplifying inspection, improving appearance. It saves power, labour and quick return on original investment.
5.Q32 Series Tumble Belt Type Shot Blasting Machine has the advantages of advanced design,reasonable structure small energy consumption and high efficiency.
Bolts and screws rubbertrack shot blasting equipment Technical Parameter
| Type | Q326 | Q3210 | QR3210 | Q3220 |
| Productivity(t/h) | 0.6-1.2 | 3-5 | 2-2.5 | 4-5 |
| Feeding amount(kg) | 200 | 800 | 600 | 1200 |
| Maximum weight of workpiece(kg) | 10 | 150 | 30 | 50 |
| Diameter of end disk(mm) | Φ650 | Φ1000 | Φ1000 | Φ1000 |
| Effective volume(m³) | 0.15 | 0.4 | 0.3 | 0.6 |
| Abrasive flow rate(kg/min) | 120 | 250 | 250 | 2*250 |
| Workpiece speed(m³/h) | 2000 | 6000 | 3500 | 8000 |
| Power consumption(kw) | 12.6 | 32.6 | 24.3 | 53 |
| Out line dimention(mm) | 1500*1880*3900 | 3644*2926*5856 | 3976*2600*4768 | 7200*3500*5800 |
Bolts and screws rubbertrack shot blasting equipment service
1.Reply you in the 24h
2.Reply you in English
3.crawler type shot blasting machine Design according to technical requirement
4.Special discount and protection of sales are provided to distributor of crawler type shot blasting machine
5.We could do the crawler type shot blasting machine field test to show the machine operation and work effect
6.We are crawler type shot blasting machine manufacture, we could promise the quality and price
Qingdao Rovan Machinery Co., Ltd
1.Established in 2001the factory is located in Qingdao, China.
2.Mainly manufacture shot blasting machine, crawler type shot blasting machine dust collector, microseism squeeze molding machine/sand molding machine, core shooter machine, resin sand production line, clay sand production line, etc.
3. All products has ISO9001 and CE certification,
4. OEM also could provide for you.
