BW-2T-DJ Stripping and crimping terminal crimping machine

Product features:

1. The machine is controlled by advanced frequency converter, variable frequency motor, and equipped with imported high precision approaching switch and reducer, which are accurate in operating and pre-feeding, high in efficiency.

2. The machine is designed in environmental protecting Model, which is low noise, power saving, wider adjusting range for the width, higher precision for adjustment, saving the crimping adjusting time.

3. The crimping height could be directly adjusted on the operating panel.

4. The machine especially processes the fine cable for the elevator, multi-layers shielded cable, internet cable and etc.

5. It has the two functions of stripping and crimping that taken at one time.

Technical parameters:

1. Model: BW-2T-DJ

2. Specification: 300 x 340 x 650 mm

3. Weight: 60kg

4. Crimping force: 20kn

5. Average power consumption: 0.45kw

6. Motor power: 0.75kw

7. Power: 220v 50Hz

8. Travel distance: 30mm

9. Stripping range: 18-34 AWG#

Localisation : No. 39 Kun Lun Road, Xin Bei District, Changzhou, Jiangsu Province, China , 213118 Changzhou,
Personne à contacter : Leo Lee, +86 519 85912300
