Casting Alloy Steel Blow Bars for Crusher
Quantité : 5000 Prix : USD 1000-3000/ Ton
Casting Alloy Steel Blow Bars for Crusher Specification
1.Component: super high manganese steel and high chromium alloy steel
2.Manufactured with super high manganese steel, therefore it has a service life of 50 to </ span>
100% longer than those made of traditional high manganese steel
3.Special processing techniques ensure that our jaw plate has leading performance
4.We can offer all kinds of Crusher spare parts, impact liner, blow bar, hammer plate.
crusher parts, usually with high chrome material.
If you are interested in any of the parts, as long as you provide us the drawing and
material requirement, we will quote the competitive price for you.
Impact Crusher Blow Bars Main Features and Benefits:
1. 10 years experience in casting
2. High efficiency;
3. Works well and easy maintenance.
4. it creates a new field for many customers in the choice and matching of high wear
and tear spare parts.
5. can be used in serious abrasion
Business scope:
Bimetal thermal-composite materials series, alloyed high manganese & super
high-Manganese hammer series, Medium & high alloy steel material series,
High chromium alloy iron wear resistance products as hammer head,board hammer,
hammer's block, lining plate ,jaw plate and comb plate.
Material Specifications of High Manganese Blow Bar for Crushers
|
Code Elem |
C |
Mn |
Si |
Cr |
Mo |
P |
S |
|
ZGMn13-1 |
1-1.45 |
11-14 |
0.3-1 |
- |
- |
≤0.09 |
≤0.04 |
|
ZGMn13-2 |
0.9-1.35 |
11-14 |
0.3-1 |
- |
- |
≤0.09 |
≤0.04 |
|
ZGMn13-3 |
0.9-1.35 |
11-14 |
0.3-0.8 |
- |
- |
≤0.09 |
≤0.04 |
|
ZGMn13-4 |
0.9-1.3 |
11-14 |
0.3-0.8 |
1.5-2 |
- |
≤0.09 |
≤0.04 |
|
ZGMn13-5 |
0.75-1.3 |
11-14 |
0.3-1 |
- |
0.9-1.2 |
≤0.09 |
≤0.04 |
Material Specifications of High Cr Blow Bar for Crushers
|
High Chrome Casting Material Chemical Composition |
||||||||||
| Code Elem. | C | Si | Mn | Cr | Mo | Na | Cu | P | S | HRC |
| KmTBCr4Mo | 2.5-3.5 | 0.5-1.0 | 0.5-1.0 | 3.5-4.5 | 0.3-0.5 | - | - | ≤0.15 | ≤0.10 | ≥55 |
| KmTBCr9Ni5Si2 | 2.5-3.6 | 1.5-2.2 | 0.3-0.8 | 8.0-10.0 | 0-1.0 | 4.5-6.5 | 4.5-6.5 | - | - | ≥58 |
| KmTBCr15Mo | 2.8-3.5 | ≤1.0 | 0.5-1.0 | 13-18 | 0.5-3.0 | 0-1.0 | 0-1.0 | ≤1.0 | ≤0.06 | ≥58 |
| KmTBCr20Mo | 2.0-3.3 | ≤1.2 | ≤2.0 | 18-23 | ≤3.0 | ≤2.5 | ≤1.2 | - | - | ≥60 |
| KmTBCr26 | 2.3-3.3 | ≤1.2 | ≤1.0 | 23-30 | ≤3.0 | ≤2.5 | ≤2.0 | - | - | |
