CE RoHS High Power LED Rainproof Metal Power Supply 200W 240W 5V/12V/24V

Quick DetailsPlace of Origin: Zhejiang,Website: http://www.cn-ledstrips.com, China (Mainland)Brand Name: hviele FS-400W LED rainproof i v supplies power supplyModel Number: FS-400WOutput Power: 301 - 400WOutput Type: SingleInput Voltage: 180~264VAC,255~373VDCOutput Voltage: 12V 15V 24V 36V 48VOutput Frequency: 47~63HZOutput Current: 33A 27A 16.5A 11A 8.3ASupply ability: 10000 pcs for one monthDemension: 236*135*65mm (L*W*H)Packing: 1.4kg/12pcs/17.5kg/0.039m³/1.36CUFTAC current: 4.0A/230VACWorking temp,humidity: -10℃~+60℃,20%~90%RHWarranty: 2 yearsWithstand vibration: 10~500HZ,2G 10min/1cycle,period for 60 minutes,each axesSafety standard: Fit UL1012 IP44Efficiency: 82% 84% 85% 86%Packaging & Delivery Packaging Details: 1.4kg/12pcs/17.5kg/0.039CBM/1.36CUFT Delivery Detail: 3 days for minor order & sample,and 2-4 weeks for bulk order FS-400W LED rainproof i v supplies power supply1.Features: ·170~264VAC AC input·Small volume,low weight,high efficiency·Protections: short circuit/over load/over voltage/over temp·Built-in cooling DC fan·Fully encapsulated with IP44 level·100% full load burn-in test·2 Year warrantyProduct Description2. The Specification of FS-400W LED rainproof i v supplies power supply : Model FS-400-12 FS-400-15 FS-400-24 FS-400-36 FS-400-48 output DC voltage 12V 15V 24V 36V 48V Voltage tolerance ±1% ±1% ±1% ±1% ±1% Rated current 33A 27A 16.5A 11 8.3 Current range 0~33A 0~27A 0~16.5A 0~11A 0~8.3A Rated power 396W 405W 396W 396W 398.4W Ripple&noise 150mvp-p 150mvp-p 200mvp-p 200mvp-p 200mvp-p DCvoltage ADJ.range ±10% ±10% ±10% ±10% ±10% input Voltage range 180~264VAC,255~373VDC frequency 47~63HZ AC current 4.0A/230VAC efficiency 82% 82% 84% 85% 86% Inrush current Cold start current 50A/230VAC Leakage current < 3.5mA/240VAC protection overload Rated output power105%~135% start over load protection protection type: hiccup mode,auto-recovery after fault condition is removed over voltage 15.6~17.8V 18.6~20.8V 30.6~33.2V 42.6~44.2V 54.8~56.6V protection type: hiccup mode,auto-recovery after fault condition is removed over temperature TSW1detect on heatsink of power transistor≥85°C±5°C, start over temperature protection protection type: hiccup mode,auto-recovery after temperature become normal environment Working temp,humidity -10°C~+60°C,20%~90%RH Storagetemp,humidity -20°C~+85°C,10%~95%RH non-condensing Withstand vibration 10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes safety Withstand voltage I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC Isolated resistance I/P-O/P,I/P-FG,O/P-FG: 100M ohms/500VDC Fitstandard Safety standard Fit UL1012 IP44 EMC standard EN55022,CLASSA others Dimension 236*135*65mm (L*W*H) Weight/packing 1.4kg/12pcs/17.5kg/0.039m³/1.36CUFT note 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation.
