Centrifuge
Quantité : 1-100 Prix : USD 50000-5000000
HVD-TCF-P is an automated upper suspension centrifuge device with mechanical unloading. All parts contact with the material and water, steam pipeline is made of stainless steel or corrosion resistant materials, to ensure the cleanliness of the separated products. Using pneumatic mechanical scraper discharge, centrifuge instrument makes unloading safe and reliable and suitable for separating suspension containing medium and fine particles crystal. If you want to buy commercial centrifuge, Hongvadar is the best choice for you as one of the qualified centrifuge companies.
Centrifuge Application
HVD-TCF-P automated upper suspension centrifuge is mainly used for centrifuge dewatering of a saccharide in sugar industry, but also for the separation of solid and liquid of the B saccharide, grape saccharide or similar crystal materials with high viscosity and high concentration. Centrifugation in food processing is really common.
Centrifuge Main Advantages
Automatic control to ensure the separation effect;
Stepless speed regulation;
Wide speed range;
Large starting and braking torque;
Good low speed centrifuge capacity;
Centrifuge Technical Parameters
Model |
HVD-TCF1400-P90 |
HVD-TCF1600-P110 |
Drum inner dia. mm |
φ1348 |
φ1600 |
Max. drum rotary speed, rpm |
1410 |
1100 |
Max. separation factor |
1500 |
1083 |
Drum effective volume, L |
778 |
1089 |
Max. material loading qty. kg |
1300 |
1750 |
Power, kW |
90 |
110 |
Overall dimension, mm |
2420×1910×4820 |
2240×2160×5100 |
Weight, kg |
9000 |
9500 |
Beijing Hongvadar Engineering Technology Co. Is a professional hydrocyclone manufacturers, we provide corn starch production plant, continuous crystallization equipment, automated centrifuge and etc. For more info or buy centrifuge, contact us.
Personne à contacter : Li Danny, +13 8 11 96 92 27
