China OEM plant UL3272 XLPE sheath UL style 600V Hook-Up Wire
Quantité : 1000meter/ Prix : USD 0.01-0.03 /meter
UL3272 XLPE sheath UL style 600V Hook-Up Wire
Description:
UL3272 hook up wire is made of tinned copper, the insulation is XLPE,the conductor is usually 19 strands, elesun cable can produce from 22awg to 10awg to meet different application requirements.
Application :
UL style 3272 lead wire is a general-purpose electronic hook up wire, used in the internal wiring of appliances and electronic equipment, it can resistant to water, oil, acid, solvent and fungus . The jacket is PVC ,the rated voltage is 600 voltage, it can be used where temperatures range from -20℃ to +125℃. UL 3272 lead wire can also use as internal wiring in appliances that are exposed to oil which does not exceed 125℃ in temperature.
Tips: What is XLPE?
XLPE is the abbreviation of cross-linked polyethylene, polyethylene is a linear molecular structure, easily deformed at high temperatures. The cross-linked polyethylene process makes it into a network structure. This structure, even at high temperatures, has a strong resistance to deformation. XLPE cable material is a kind of organic peroxide containing polyethylene. This peroxide in high temperature and high pressure and inert gas environment, and polyethylene chemical reaction,that is XLPE.
Best Properties of XLPE hook up wire:
1. XLPE cable has excellent electrical properties.
2. Dielectric loss is lower than PVC insulation .
3. Capacitance of XLPE cable is good.
4. Easy to lay the XLPE cable such as UL3272 is another advantage. XLPE cable has a smaller bending radius, which is lighter than other similar cables and has a relatively simple terminal handling.
5. XLPE hook up wire does not contain oil, so when lay XLPE cables, you need not consider the route, there is no oil due to drip and laying of the situation.
The UL3272 lead wire produce by elesun cable is compliant to ROSH
UL style 3272 AWM 3272 hook up wire specifications |
|
Material of Inner Conductor |
Tinned copper |
No. of Inner Conductor |
Solid , 19 strands, 41 strands |
Material of Jacket |
PVC |
Diameter of jacket |
From 22 awg to 1 awg |
Rated Working Temp |
-20℃ to +125℃ |
Voltage |
600V |
Conductor structure and Resistance
AWG |
Conductor Structure (NO.of strands) |
20℃ Max Resistance (Ω/km) |
Min Insulation Thickness(mm) |
22 |
1,7,17 |
54.3 |
0.79 |
20 |
1,7,21 |
33.9 |
0.79 |
18 |
1,7,16 |
21.4 |
0.79 |
16 |
19,65 |
13.5 |
