Compasite geonet for drainage

Tri-dimension composite genet for drainage is a new type of geosynthetics.Its made of atri-dimension geonet coated with geotextile on both sides. Network core consists of a tri-dimension thick vertica l rib, and a rip on top and bottom .It can drain underground water quickly, also there is a protecti on system,which can block the capillary water under high load. At the same time, it can also reinfor ce and isolate of foundation.

Specifications:

core thickness: 5 mm - 8 mm; width 2 - 4m, composite geotextile: short fiber needle punched geotextile, filament spunbonded needle punched geotextile, the length at request.

Properties:

Tri-dimension composite geonet for drainage is made of a unique tri-dimension geonet coated with geo textile on both sides. It has the property of geotextile(filtration) and geonet (drainage and protec tion) and provide a function system of“filtration-drainage-protection”. The tri-dimension structure can bear higher load in construction and remain certain thickness,strength and excellent in water co nductivity.

Application:

drainage in landfill; roadbed; railway,tunnel,underground structure,the retaining back wall, gardens and sports grounds.
