Conical Horn Antenna
HBTE conical horn antenna with a careful design and produce process is widely used in EMI detection, directional detection, antenna measurement, darkroom test and other fields. Its working frequency from 18Ghz to 40Ghz and its standard gain from 12 dB to 25dB. Conical horn antenna provides monopolarization and dual polarization.
Great circular symmetry pattern
High Gain
Excellent VSWR and isolation
Wide bandwidth
|
No |
Model |
Frequency （Ghz） |
Polarization |
Gain （dB） |
VSWR |
Isolation （dB） |
Connector |
Size（mm） |
Withstand power（W） |
|
1 |
SH-18-30-D25 |
18-30 |
single polarization |
25 |
＜2 |
/ |
2.92-K |
274*φ100 |
20 |
|
2 |
SH-24-30-D25 |
24-30 |
single polarization |
25 |
＜2 |
/ |
2.92-K |
291*φ98 |
20 |
|
3 |
DH-24-30-D25-OMT |
24-30 |
Dual polarization |
25 |
＜2 |
＞30 |
2.92-K |
341.4*φ99.8 |
20 |
|
4 |
DH-24-40-D20-OMT |
24-40 |
Dual polarization |
20 |
＜2 |
＞30 |
2.92-K |
176.4*φ98 |
20 |
|
5 |
DH-24-40-D23-OMT |
24-40 |
Dual polarization |
23 |
＜2 |
＞30 |
2.92-K |
275.4*φ98 |
20 |
|
6 |
DH-24-43.5-D12-OMT |
24-43.5 |
Dual polarization |
12 |
＜2 |
＞30 |
2.4-K |
85*φ98 |
20 |
|
7 |
DH-30-40-D25-OMT |
30-40 |
Dual polarization |
25 |
＜2 |
＞30 |
2.92-K |
291.4*φ98 |
20 |
HBTE technology provides positioning equipment, antenna measurement system, etc. Want to know more, please contact us.
Personne à contacter : Tech HBTE , 021 59830621
