Coriolis mass flow meter oil meter
Technical Parameters
Specification AMF050
Nominal diameter DN50 (2 inch)
Max flow rate 1000Kg/min
Working pressure <=4MPa (580 Psi)</p>
Accuracy level
(customizable) 0.15 ,0.2 ,0.5 , 1.0 optional
Density: 0.001g/cm
Repeatability 0.075% ,0.1% ,0.25% ,0.5% optional
Measuring medium Liquid / Gas / Multiphase flow
Output signal Current 4~20mA / Pulse / Modbus RS485
Current output Passive: 4~20mA (Active: DC 15~36V)
Pulse output signal 1~10000Hz, representative flow rate,electrical level 0~12VDC,load>=2kOU
When the flow rate is zero, the pulse output frequency is 0 Hz.
The rated pulse output frequency under rated flow rate can be set by the user.
Modbus RS485 The default baud rate of RS-485 is 38400bit/s.
Power supply AC/DC 15~36V
Ambient temperature -40C~+70C
Medium temperature -196C~+100C
Related humidity <=95%</p>
Measuring pipe material 304, 304L, 316, 316L, Babbitt alloy
Connection mode
(customizable) Flange / Screw thread optional
The explosive-proof mark Exdib IIB T5 Gb
