DC12V 24W 60W Non Waterproof LED Power Supply CE Approved

Quick DetailsPlace of Origin: Zhejiang, China (Mainland)Brand Name: SteadyModel Number: NES-150-48Output Power: 101 - 200WOutput Type: SingleInput Voltage: 85 ~ 132VAC / 176 ~ 264VAC selected by switch 248 ~ 373VDCOutput Voltage: 48VOutput Frequency: 47~63HzOutput Current: 3.3AEfficiency: 86%Certification: CEGuarantee: 2 yearsCase material: AluminiumDimension: 199*98*38mm (L*W*H)G.W: 0.7kgPackaging & DeliveryPackaging Details: it is packed by vacuum plastic bag to provent moisture and then put into the inner box,20 pcs to a neutral carton.Delivery Detail: 3-30daysProduct DescriptionFeatures : •AC input range selectable by switch• Protections: Short circuit / Overload / Over voltage•Cooling by free air convection•LED indicator for power on•100% full load burn-in test•High efficiency, long life and high reliability•2 years warrantyMODELNES-150-5NES-150-7.5NES-150-9N ES-150-12NES-150-15NES-150-24NES-150-48OUTPUTDC VOLTAGE5V7.5V9V12V15V24V48VRATED CURRENT26A20A16.7A12.5A10A6.5A3.3ACURRENT RANGE0 ~ 26A0 ~ 20A0 ~ 16.7A0 ~ 12.5A0 ~10A0 ~ 6.5A0 ~ 3.3ARATED POWER150W150W150W150W150W150W150WRIPPLE & NOISE (max.) Note.280mVp-p120mVp-p120mVp-p120mVp-p120mVp-p120mVp-p150mVp-pVOLTAGE ADJ. RANGE4.75 ~ 5.5V7.13 ~ 8.3V8.55 ~ 9.9V11.4 ~ 13.2V14.25 ~ 16.5V22.8 ~ 26.4V45.6 ~ 52.8VVOLTAGE TOLERANCE Note.3±2.0%±1.0%±1.0%±1.0%±1.0%±1.0%±1.0%LINE REGULATION Note.4±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%LOAD REGULATION Note.5±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%SETUP, RISE TIME500ms, 20ms/230VAC 500ms, 20ms/115VAC at full loadHOLD UP TIME (Typ.)30ms/230VAC 25ms/115VAC at full load INPUTVOLTAGE RANGE85 ~ 132VAC / 176 ~ 264VAC selected by switch 248 ~ 373VDCFREQUENCY RANGE47 ~63HzEFFICIENCY(Typ.)80%81%81%83%84%86%86%AC CURRENT (Typ.)2A/115VAC 1.2A/230VAC INRUSH CURRENT (Typ.)COLD START 36ALEAKAGE CURRENT<2mA/ 240VAC PROTECTIONOVERLOAD110 ~ 150% rated output powerProtection type : Hiccup mode, recovers automatically after fault condition is removedOVER VOLTAGE5.75 ~6.75V8.6 ~ 10.1V10.4 ~ 12.2V13.8 ~ 16.2V17.25 ~ 20.25V27.6 ~ 32.4V55.2 ~ 64.8VProtection type : Hiccup mode, recovers automatically after fault condition is removed ENVIRONMENTWORKING TEMP.-20 ~ +60”C (Refer to "Derating Curve")WORKING HUMIDITY20 ~ 90% RH non-condensingSTORAGE TEMP., HUMIDITY-40 ~ +85°C, 10 ~95% RHTEMP. COEFFICIENT±0.03%/°C (0 ~ 50°C)VIBRATION10 ~ 500Hz, 2G 10min./1cycle, period for60min. each along X, Y, Z axes SAFETY &EMC(Note 6) SAFETY STANDARDSUL60950-1, CB(IEC60950-1),CCC GB4943 approvedWITHSTAND VOLTAGEI/P-O/P: 1.5KVAC I/PFG: 1.5KVAC O/P-FG: 0.5KVACISOLATION RESISTANCEI/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25°C/ 70% RHEMC EMISSIONCompliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3EMC IMMUNITYCompliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-1, light industry level, criteriaA OTHERS MTBF433.3Khrs min. MIL-HDBK-217F (25°C)DIMENSION199*98*38mm (L*W*H)PACKING0.7Kg; 20pcs/14Kg/0.72CUFT NOTE1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.2.Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1 uf & 47uf parallel capacitor.3.Tolerance : includes set up tolerance, line regulation and load regulation.4.Line regulation is measured from low line to high line at rated load.5.Load regulation is measured from 0% to 100% rated load.6.For the request of GB4943.1 ,the power supply is only suitable for use in the altitude 2000m below and the non tropical climate condition.7.The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.”(as available on http://www.meanwell.com)8.Length of set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time.Product application: • Power tools series: Electric Saw, Drilling Machine, Ginder, Sand blast Machine, Puching Machine,Weeding Machine,Air Compressor etc. • Office series: Computer,Printer,LCD Monitor,Scanning Machine etc.• Household Appliance series: Dust Collector,Fan Lamp or LED ,Sewing Machine etc.• Kitchen Appliance series: Microwave Oven, Fridge, Freezr, Coffemarker etc.• Industrial Equipemnt series: shipping,vehicle,metalhalide lamp,solar system,wind power generation ect.• Electrical filed series: TV,VCRS,Radio ect. url: http://www.cn-ledstrips.com
