EDM Best Quality Brass Wire
Quantité : 200kg Prix : USD6.5/kg
Detail for Brass Wire
- Material: good-quality brass
- Weight/spool: 3, 5, 7, 15 and 20kg
- Tensile strength: 1,000, 900, 500 and 400N per square millimeter
- Alloy number: C28000/C27400/C27000/C26000
- Diameter: 0.1 to 80mm
Features
- Good cold processing plasticity, elasticity and high strength
- Suitable to be made into eyeglasses accessories, rivets, battery axle, fasteners, springs, borers and soldering wires and cutting lines
- Numbers: H62, H63, H65, H68, H70, H85, H90 and H95
- Features: plastic cold working fine
- Good flexibility
- Superior cutting performance
- High surface finish
- High impurity content
- Used on wire cutting machines like Agie Charmilles, Sodick, Mitsubishi and Makino
- Delivery lead-time: 15 days after the receipt of 30% deposit
- Packing: carton and wood pallet, roll spool pallet or customized
Application: Suitbale for various slow cutting speed machines for tool maufacturing
Main technology standard of Copper Electrode Wires
Type |
Standard Diameter (mm) |
Tolarance (mm) |
Tensile Strength |
Breaking Load (Kgf) |
Conductivity (%) |
Hard | 0.100 | +/-0.001 | ≥980 | 7.70-9.20 | 22min |
0.150 | 17.4-20.0 | ||||
0.200 | 30.5-37.0 | ||||
0.250 | 48.1-57.5 | ||||
0.300 | 62.6-76.3 | ||||
Soft | 0.100 | +/-0.001 | ≤550 | 3.40-4.12 | 25min |
0.150 | 7.75-9.22 | ||||
0.200 | 13.8-16.3 | ||||
0.250 | 21.1-25.5 | ||||
0.300 | 31.2-36.7 |
Our Company:
AVIC Xinxiang Bashan Aero Material Co., Ltd
In more than 62 years experience of metal wire cold drawing, metal wire mesh weaving and deep processing products, Bashan company acquired 24 metal wire & mesh patents and took chief part of 19 standards, such as GB/T4240, GB/T5330, GB/T6003, GJB107, HB1862, etc. (GB/T, national standard; GJB national military defense standard; HB, aviation standard. )
Contact: Maggie Guan
Personne à contacter : Maggie Guan, +86 373 3091998
