Fibreglass rodder duct fish snake cable puller 4.5mm x 100 mtrs

Donnez votre avis

Lire les avis

Ajouter au pense-bête

Imprimer

3.3/5
1
2
3
4
5

Détails

Chine (Rép. pop)

Biens d'équipement

Fibreglass rodder duct fish snake cable puller 4.5mm x 100 mtrs

Quantité : 1000 meter Prix : 0.5 usd/meter

Technical Date of Fiberglass Duct Rodder

Specification

Rod Diameter (mm) Φ 4.5-Φ 16

Rod Length (m) 30m~500m

Frame Spec. (mm) 1300x450x1330,1200x420x1220,980x350x1000,680x240x700, 420x180x400,etc.

Material: Fiber glass rod inner, Extruded by fiber glass and high strength resin at high temperature

Fiber glass rod outer, High Density polyethylene coating

Metal Frame: Steel with high-temperature sprayed plastic or hot dip galvanized

Physical Property

Fiber glass content: 75-80%

Density > 1.9gr/cm3

Working environment-40° C to +80° C

Minimum Pulling strength 4000N +/-5%

Consistency of rod 137gr/m

Flexural Modulus > 46.500Mpa

Elongation at break 2.5-3%

Min Bending Radius 388mm

Fiberglass duct rodder is an auxiliary tool applied in towing lead-rope through a pipe. The rod surface is hard and smooth, so it can get through the narrow pipe or channel easily.The inner core of the rod is made of fiberglass and unsaturated polyester resin. The outside layer is smooth and firm ABS resin. It is widely used for the cables works or cleaning in cable pipe or channels. It has the advantages of time saving,reducing effort, improving efficiency etc.

Localisation : bazhou hebei China, 065700 bazhou,
Personne à contacter : bazhou china, 86 0316 7399000
