Finishing high quality walking wire cutting EDM brass wire by bashan

The description of Finishing high quality walking wire cutting EDM brass wire by bashan

Raw Material: Cuzn35, Cuzn37?, H62
Wire Diameter: 0.30mm, 0.25mm, 0.20mm,
0.15mm, 0.10mm
Wire Condition: Hard, Semi-hard, Soft
Tensile Strength: 1000, 900, 500, 450 N/㎜²
Conductivity: Above 20% IACS
Spool Type: P3, P5, P10, P20, DIN125, DIN160, DIN200
Weight/Spool: 3~20kg
Packing: PE film sealed, moisture proof, quake proof, corrosion resistance.
Applications: Used on wire-cut machine of Agie, Charmilles, Sodick, Mitsubishi, Makino etc.

The Specification of Finishing high quality walking wire cutting EDM brass wire by bashan

Brass EDM Wire Features

¤ Various of wire core material can match demands
of different wire-cute machine.

¤ Heat treatment technology ensures tensile strength
stability, and prevents damage of wire.

¤ Superior verticality suitable for automatic threading.

¤ High drawing precision, fine ovality, low tolerance.

Reliable Raw Materials

Good and reliable raw material is the most important factor of producing excellent fine stainless steel wire. Bashan company use good raw materials from well-known iron manufacturers at home and abroad. Ugitech in France, Hikari Works in Japan, Tisco in China, D&B Special Steel in China, Ruipu in China, etc.

Brass EDM Wire Advantages

¤ The only professional military manufacturer of stainless steel wire and brass edm wire.

¤ More than 60 years experience of metal wire drawing and wire mesh weaving.

¤ Certified in accordance with GB/T ISO 9001: 2008, ISO/TS16949: 2009 quality system.

¤ Use reliable raw material, well-equipped workshop and skilled workers.

¤ 300 tons of brass edm wire annually

¤ Have independent import and export rights since 1996

Our company

Xinxiang Bashan Aero Material Co., Ltd., affiliated to China Aviation Industry Corporation (AVIC), is the only professional military manufacturer of Metal wire, Metal wire mesh, Filter element, Special filtration component and Thread insert.
In more than 60 years experience of metal wire cold drawing, metal wire mesh weaving and deep processing products, Bashan company acquired 24 metal wire & mesh patents and took chief part of 19 standards, such as GB/T4240, GB/T5330, GB/T6003, GJB107, HB1862, etc. (GB/T, national standard; GJB national military defense standard; HB, aviation standard.)
