GEMQD-770J Hand-Held Pneumatic Marking Machine
GEMQD-770J Series of portable hand-held flat pneumatic marking machine, computer editing, but also configure the microcontroller controller, small size, light weight, mobile printing; suitable for large equipment, heavy parts of the field hand-held printing, such as large pipe, frame and so on. You only need to edit the contents of the computer to be printed, and then hand-held mark the first alignment to print the location, gently press the trigger switch, neat and beautiful logo to print out the content
Hand-Held Pneumatic marking machine -GEMQD-770J Features
1. handheld pneumatic marker Optional ordinary computer or ultra-small embedded single-chip control.2. Can be the completely off-line operation, friendly man-machine interface, easy to learn and use, simple operation.3. Can automatically print Chinese characters, numbers, graphics, serial number,code and so on.4. Print content unlimited storage, will not be lost due to power failure.5. Needle with carbide material, print material hardness can reach HRC60.6. Anti-interference, anti-radiation ability, to adapt to the harsh environment of the work site.7. Rack with aviation aluminum, lightweight, small size, print area, high strength, is similar products cannot achieve the effect, comparable with similar foreign products.8. Chassis with aluminum box, control system, and operating system integration, the printer head can be placed in the chassis, easy to carry
Hand-Held Pneumatic marking machine -GEMQD-770J Specifications
|
Model |
GEMQD-770J |
|
Print range |
80 * 140mm (optional) |
|
Maximum print hardness |
HRC62 |
|
Printhead lift height |
0 ~ 300mm |
|
Compressed air pressure |
0.3 to 0.7 MPa |
|
Repeat print accuracy |
0.02mm |
|
Voltage requirements |
AC176 ~ 264V |
|
Print the smallest character |
1mm |
|
Total power |
300W |
|
printing speed |
1 to 3 characters per second |
|
Ambient temperature |
-10 ° C to 50 ° C |
|
System reset times |
1000 times |
|
Continuous working hours |
> 48 hours |
Hand-Held Pneumatic marking machine -GEMQD-770J Applications
GEMQD-770J is mainly used in valves, machinery, automobiles, motorcycles, aerospace, electronics, military, light industry and other fields can be steel, iron, copper, aluminum, plastic and other materials to print partsLaser Marked Sample


webiste: http://www.gem-lasers.com/laser-products/gemqd-770j-hand-held-pneumatic-marking-machine.html
company: GEM LASER LIMITED
contact: 86-27-84793136
email: sales@gem-lasers.com
