German Types Carbon Steel High Quality Hose Clamp For All Size
German Types Carbon Steel High Quality Hose Clamp For All Size
Other products we can provide you:
We can provide all types Hose Clamps
Specifications 1:
1) Band width:128px"margin: 0px; padding: 0px; border: 0px; font-family: inherit; font-size:18px; font-style: inherit; font-variant: inherit; font-weight: inherit; line-height: 27px; vertical-align: baseline; color: rgb(0, 0, 255);">2) Band thickness: 0.6mm, 0.65mm, 0.8mm or Customer requirement
4) Material: stainless steel, carbon steel or Customer requirement
Specifications 2:
Screw : 7mm hex-head .Carbon steel or 400/200/300 grade stainless steel .
Band : 9mm/8mm/12mm bandwidth . Non-perforated .Carbon steel or 400/200/300 grade stainless steel .
Housing : Carbon steel or 400/200/300 grade stainless steel .
Advantages:
1.The outer edge of the band with smoothing and shaping treatment precludes the damage of the hose.
2.using high quality material and precise stamping molding, prevents thread stripping.
3.with precise design, uniform stress, good sealing ability, can be twisted smoothly, and used multiple times.
Chart of size and clamp range
| SAE Sizes | min.dia.(in.) | max.dia.(in.) | min.dia.(mm) | max.dia.(mm) |
| 6 | 3/8 | 7/8 | 10 | 22 |
| 8 | 7/16 | 1 | 11 | 25 |
| 10 | 1/2 | 1-1/16 | 13 | 27 |
| 12 | 1/2 | 1-1/4 | 13 | 32 |
| 16 | 11/16 | 1-1/2 | 18 | 38 |
| 20 | 3/4 | 1-3/4 | 19 | 44 |
| 24 | 1 | 2 | 25 | 51 |
| 28 | 1-1/4 | 2-1/4 | 32 | 57 |
| 32 | 1-1/2 | 2-1/2 | 38 | 63 |
| 36 | 1-3/4 | 2-3/4 | 44 | 70 |
| 40 | 2 | 3 | 51 | 76 |
| 44 | 2-1/4 | 3-1/4 | 57 | 82 |
| 48 | 2-1/2 | 3-1/2 | 64 | 89 |
| 52 | 2-3/4 | 3-3/4 | 70 | 95 |
