H05V-K H05V-R H05V-U Cable
H05v-r cable, h05v k wire, h05v u cable is PVC electrical wiring, made of bare copper conductor and PVC insulation material, conforms to the European harmonized standard, used for building, internal wiring of electrical switchboards, power distribution cabinet and telecommunications equipment, can be used for equipment exported to Europe, and also recommended as a replacement wire for European-made MRO.
H05V-K H05V-R H05V-U Features
01.
Application
This type of building wire for sale is for electrical panel wiring, home use, industrial use, commercial use.
02.
Voltage
300/500V
03.
Standards
European harmonized standards, ROHS environmental standards
04.
Operating Temperature
-5℃-70℃
Specifications of H05V-K H05V-R H05V-U
300/500V, H05V-U
300/500V,H05V-R
300/500V, H05V-K
|
300/500V, H05V-U |
||||||
|
Nominal Cross Section |
Conductor Construction |
Insulation Thickness |
Overall Diameter |
Approx. Net Weight |
Max. Conductor Resistance at 20℃ |
|
|
mm2 |
No. |
Diameter |
mm |
mm |
kg/km |
Ω/km |
|
1 X 0.5 |
1 |
0.8 |
0.6 |
2 |
8.16 |
36 |
|
1 X 0.75 |
1 |
0.97 |
0.6 |
2.17 |
10.71 |
24.5 |
|
1 X 1.0 |
1 |
1.13 |
0.6 |
2.33 |
13.48 |
18.1 |
If you are looking for a reliable electric wire company, don't hesitate to contact us!
