H3G-THWL Battery Management System
H3G-TH WL active balancing battery management system adopts a new generation of ZigBee wireless communication technology, which reduces on-site wiring by half and avoids hidden safety dangers of too many cables. It features convenient installation and shortens the on-site construction period. This BMS for lead acid battery is mainly applied in communication base stations, substations, enterprise data rooms, and other fields.
Features of H3G-THWL active battery management system
ZigBee Wireless Communication
Real-time Data Monitoring and Alarming
Advanced Low Power Consumption Design
High-accuracy SOC/SOH（5）AI data analysis
Function of H3G-THWL Wireless Management System
Charge/Discharge current
String Voltage
Ambient Temperature
SOC/SOH
Cell Internal Resistance
Cell Voltage
Intelligent Equilibrium
Cell Temperature
Specification of H3G-THWL Battery Management System
|
Measuring content |
Range |
Accuracy |
Resolution |
|
Sting voltage |
20～800V |
±0.5% |
0.1V |
|
Cell voltage |
2V,12V |
±0.1% |
0.001V |
|
Cell internal resistance |
50～65535μΩ |
±2%（repetitive accuracy） |
1μΩ |
|
Temperature |
-5～+99.9°C |
±1°C |
0.1°C |
|
Charge/Discharge current |
±1500A |
±1% |
0.1A |
|
SOC/SOH |
— |
±5% |
1% |
As one of the most battery management system suppliers, Huasu provides bms battery in china, bms battery management system, etc. For more information, please feel free to contact us!
