HC-320A Blank Label Turret Slitter Rotry Die Cutter
HC-320A Blank Label Turret slitter die Cutter
This slitter is ideal machine for the adhesive label, paper roll slitting.
Features of HC-320A Blank Label Turret Slitter Rotry Die Cutter
Use of HC-320A Automatic Blank Label Slitting Rotary Die Cutting Machine
HC-320A Automatic Blank label slitting rewinding machine with Turret is the most ideal machine for label slitting.
It have other functions such as: automatic inspection, automatic correcting, automatic counter etc, can be finished in once process.
Characteristic of HC-320A Automatic Blank label slitting machine
Synchronous belt transmission, can assure the noise much smaller.
1 inch ,2 inch ,3 inch tube all can be used for this type machine .
Air shaft rewinding .
Taper tension controller adopted for more friendly tension control of unwinding and rewinding unit .
EPC/LPC uses photocell correction.
Specifiction HC-320A Blank Label Turret Slitter Rotry Die Cutter
Technical parameter:
|
Machine model |
HC-320A |
|
Slitting speed |
120m/min |
|
Die cutting speed |
80m/min |
|
Max unwinding width |
320mm |
|
Rewinding roller diameter(2 rollers) |
2*φ220mm |
|
Rewinding roller diameter (1 roller) |
φ480mm |
|
Unwinding roller diameter |
φ550mm |
|
Precision |
±0.15mm |
|
Voltage |
220V, 1 phases, 50hz |
|
Total power |
About 2.5kw |
|
Machine weight |
About 500kg |
|
Installation dimension |
1600*1100*1700mm |
Ruian Loyal Machinery Co, Ltd., is a professional slitting machine manufacturer, we provide cutting and slitting machine, copper foil slitting machine, Raloyal slitting machine, flexographic label printing machine and etc. Contact us to know more.
