Hot Dip Galvanizing Production Line
Hot dip galvanizing line is main for wire galvanizing and ready for gabion machine, chain link fence machine, barbed wire making machine, wire mesh welding machine, etc.
Metal Tech has professional team can design for different requirement of the finished wire of different wire diameter, different zinc coating thickness and different capacity. So that clients should make sure the wire diameter&wire type, zinc thickness and yearly capacity.
Specifications of HOT DIP Galvanizing Production Line
Production Capacity for Different Diameter |
|||||
No. |
Diameter (mm) |
DV (mm*m/min) |
Max. Outlet Speed (m/min) |
Single Line Production Capacity(Ton/24h) |
30 Lines Production Capacity(Ton/24h) |
1 |
Φ1.5 |
80 |
≈53 |
≈1.0 |
≈30.0 |
2 |
Φ2 |
80 |
40 |
1.5 |
45 |
3 |
Φ2.5 |
80 |
32 |
1.7 |
51 |
4 |
Φ3 |
80 |
≈26 |
≈2.0 |
≈51(25 Lines) |
5 |
Φ4 |
80 |
20 |
2.8 |
50.4(18 Lines) |
Remark: |
|||||
Advantages of HOT DIP Galvanizing Production Line
Metal tech Hot dip galvanizing line use high-quality material parts ,such like NSK bearing, PARKER hydraulic system , quenching and brazing half gear etc,strict quality management all these guarantee superior quality and long performance Hot dip galvanizing line life, also we have different quality and different zinc coating mode can meet all requirement from client.
Production Process of HOT DIP Galvanizing Production Line
Wire pay-off device(vertical)→ Straightening→ LPG Annealing→ Natural air cooling→ Water cleaning→ Turbulent smoke-free cleaning→ Water cleaning→ Plating flux→ Drying→ Hot Dip Galvanizing→ Wiping→ Cooling→ Wire take-up the device(vertical)
Gabion box machine is a professional steel wire drawing machine manufacturer, we provide weld mesh manufacturing machine, multi wire drawing machine, hot dip galvanizing line, automatic chain link fencing machine and etc. Want to know more? Contact us.
