Industrial Magnet 1 inch x1/4 inch x1/8 inch Magnetic Plate Thin Magnet Bar

Industrial Magnet 1 inch x1/4 inch x1/8 inch Magnetic Plate Thin Magnets Bar

This powerful neodymium block magnet measures 1" in length, 1/4" in width, and 1/2" in thickness, with the pull force of 18.71 lb vertically. It is made from an alloy of neodymium, iron and boron, plated with triple layers of nickel-copper-nickel for effective corrosion protection.

The applications of this neodymium block magnet include automotive, consumer electronics, home appliances, industrial equipment & automation, information technology products, medical devices and so on.

Why Choose Us

1. ISO9001: 2015 Quality Management System certified by TUV with continuous improvements.

2. 25 years experience in neodymium magnet R & D and Manufacturing with over 1000 customized designs.

3. R & D team with multiple patents led by national "scientific and technological progress" award winner.

4. Ultimate magnetic solution provided with easy communication and fast response.

Please Note:

1. All neodymium magnets are very strong and brittle.

2. Must be handled with extreme care to avoid personal injury.

3. Eye protection should be worn when handling magnets.

4. Keep the magnets away from pacemakers.

5. The neodymium magnet should NOT be for children.

SKU Code: ATECHBL007

Dimensions: 1" x1/4" x1/8"

Tolerances: ±0.05mm

Material: NdFeB, Grade N42

Plating/Coating: Ni-Cu-Ni

Magnetization Direction: through the thickness

Weight: 100 g

Br Max/Gauss rating: 13200 GS

Max Operating Temp: 80ºC (176ºF )

Atech (HTXD) is a professional magnetic conveyor manufacturers, we provide rubber coated neodymium magnets, 1 inch magnets, small cube magnets, 1 inch square magnets, magnetic plates for sale and etc. Want to know more? Contact us now.
