J453 Low Pressure Casting Machine
Summary
The machine is generally used for low-pressure die casting of colored metal and aluminium alloy.
It is application widely including the production of middle and small aluminium alloy castings autos, motorbikes, instruments, textile machines and aeronautic industry.
The machine made up of mainframe, hydraulic system, molten pool-holding furnace, liquid surface press-added device, electric control system, mold cooling system.
Technical specification
|
name of parameter: |
parameter values |
|
Volume of holding furnace（AL） |
300 Kg |
|
Size of moving mold plate |
700X700 mm |
|
space between columns |
900X900 mm |
|
moving mold plate stroke |
800 mm |
|
Min. distance between columns |
300 mm |
|
Max. distance between columns |
1100 mm |
|
opening force |
176 KN |
|
joint force |
120 KN |
|
ejector force |
176 KN |
|
Core-drawing force of static mold |
70 KN |
|
Core-drawing stroke of static mold |
150 mm |
|
work press of hydraulic system |
12 Mpa |
|
oil pump motor power |
15 Kw |
|
Holding furnace power |
24 Kw |
