JAYUAN Poly Solar Panel
Quantité : 15000Piece Prix : $0.18~$0.3/Watt;$45~
Hangzhou Jayuan, solar solution company, is a solution and export company committed to providing our clients with the best quality products related to the field of solar energy as well as electric vehicle charging. Our main focus is to give our clients the best solutions in the field of new energy. With the help of OEM manufacturing units and a team of experts, JAYUAN is able to give the best service to the customers. We take great pride in our work especially design, product quality, and after-sales services to ensure we are fully committed to our clients throughout the whole process as well as in the long term. It provide solar products, types of solar panels and polycrystalline panel,etc.
Solar Poly panels have multiple crystals of silicons instead of single crystals as in the monotype which results in the loss of efficiency and requires a much bigger size of the panel to get higher efficiency. We also provide polycrystal solar panel etc. And the polycrystalline solar panel and poly panel price, polycrystalline solar panels for sale are very cheap.
Poly solar panels have multiple crystals of silicons instead of single crystals as in the monotype. Which results in the loss of efficiency and requires a much bigger size of the panel to get higher efficiency. For the large areas and off grids often polytype is preferred due to the lower cost of the product. Product is customized and selected based on the requirement of the power which needs to be generated. Several panels can be combined to generate more power as required. Which requires to be connected with a suitable system and require a suitable environment to work more efficiently.
Features of Poly Solar Panel:
High module efficiency through superior manufacturing technology.
No power loss thanks to improved temperature co-efficient caused by 4 busbars solar cell.
Strictly control the micro-crack of solar cells and the other non-visible defect of internal modules.
The module can bear snow loads up to 5400Pa and wind loads up to 2400Pa.
Manufactured according to and certified international I Quality and Environment Management System.
Using advanced low reflection and high light transmission glass and cell sheet surface cutting technology, in the weak light environment can also play a good performance.
Specification Of Poly Solar Panel
|
Maximum Power at STC(Pmax) |
250W |
330W |
500W |
|
Optimum Operating Voltage (Vmp) |
30.68V |
37.73V |
56.16V |
|
Optimum Operating Current (Imp) |
8.15A |
8.75A |
8.904A |
|
Open-Circuit Voltage (Voc) |
36.9V |
44.89V |
66.74V |
|
Short-Circuit Current (Isc) |
9.033A |
9.621A |
9.605A |
|
Solar Cell Efficiency (%) |
17.46 |
19.2 |
19.21 |
|
Solar Module Efficiency (%) |
15.37 |
17 |
17.27 |
|
Operating Temperature |
-40to85℃ |
||
|
Maximum System Voltage |
DC1000 |
||
|
Maximum Series Fuse Rating |
15A |
||
|
Power Tolerance |
0~+3% |
||
|
STC: Irradiance 1000W/㎡, Modules Temperature 25℃, AM=1.5 |
|||
Personne à contacter : solution jayuan, 0571 63814088
Bonne affaire : acheter au vendeur
Nous vous invitons à lire nos conditions générales d'utilisations. Vous pouvez aussi vous rendre sur nos FAQ et consulter notre page d'informations sur les risques liés à la contrefaçon.
|
