Specifications

Condition: New

Production Capacity: 30-6000ton

Voltage: 380V

Power(W): 5000-25000 KW

Weight: 10t-2000t

Warranty: 1 Year

Heating source: hot blast heater

Capacity: 30-6000T/D

Installation: Engineer's Guide

Packaging & Delivery

Packaging Details: wooden container oe nude packing or other as per the client's request

Delivery Detail: Shipped in 30 days after payment

Product Description

Application of Zinc oxide rotary kiln for sale

Rotary kiln is thermal equipment to heat materials. It is widely used in the fields of cement, nonferrous metallurgy, ferrous metallurgy, refractory material, chemical, and making-paper.

Main Features of Zinc oxide rotary kiln for sale

1. Support device: advanced shaft structure, automatic temperature measuring device and electrical heating.

2. Catch wheel: including two kinds mechanical wheel and hydraulic pressure.

3. Gears: single or double. Control the rotating speed by variable motor, DE machine and frequency variable motor. Be reliable, energy –saving, and efficient.

4. Cylinder tyre bolster: lower bolster has three types: fixed, zoom and floating. The structure is simple, replacement is convenient and won't hurt cylinder.

5. Sealing equipment: there are many kinds for choice according to kiln models, including air cylinder edge sealing, spring edge sealing, and graphite block sealing and combination for above. The feather is adaptive for cylinder rotating and swing. And sealing effect is very good.

6. Kiln head hood: including stationary type and flexible type.

Working principle of Zinc oxide rotary kiln for sale

Rotary Kiln is usually working as following : The kiln is a cylindrical vessel, inclined slightly to the horizontal, which is rotated slowly about its axis. The raw material to be processed is fed into the upper end of the cylinder. While the kiln rotates, material gradually goes down towards the lower bottom, and may undergo a certain amount of stirring and mixing. Hot gases pass along the kiln, sometimes in the same direction as the process material (co-current), but usually in the opposite direction (counter-current). The hot gases may be generated in an external furnace, or may be generated by a flame inside the kiln. Such a flame is projected from a burner-pipe (or “firing pipe”) which acts like a large bunsen burner. The fuel for this may be gas, oil or pulverized coal.

Technology parameters of Zinc oxide rotary kiln for sale

Model: φ1.4×33-φ3.2×50

Diameter(mm): 1.4-3.2

Length(mm): 33-60

Heigh(mm): 3-4

Inclination(%): 0.9-42

Capacity(t/h): 0.10-3.96

Speed(r/min): 18.5-125

Weight(t): 47.5-310

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Why choose us?

Over 20 years building history

Professional tecnology team

Prompt and caring sale team

Responsible afer-sale service

Our advantages

OEM low price

Convenient traffic

Products can be customized

Oversea engineer service is available

For More Details Please do not hesitate to contact us via the following method
