Latest Industrial door/high speed door
Quantité : 10000pcs
| Fast shutter door Detail Specification | |
| Control systems | Japanese Mitsubishi Inverter, PLC and other components. |
| Dynamical systems | Motor: SEW from Germany / SEJ |
| Power: 0.75kw~2.2kw ( according to the size of the door) | |
| Fast shutter door construction | |
| Framework |
In 2mm thicknesses cold-roll steel sheets of Shanghai, Baostee, Or on request, In stainless steel INOX304/201,paint according to your order |
| Rolling shaft |
In 2mm thicknesses cold-roll steel tube with machined blocks at each and incorporating high-speed bearing |
| Cross bar | In aluminum lath |
| Curtain | made in high-density polyester fabric (Thinkness: 0.8mm or 1.5mm) |
| Self-extinguishing rate | DIN75200 |
| Color | red, yellow, orange, blue, grey etc. |
| transparent window |
transparent pvc film imported from France, various styles ,size and location according to your order.thinkness: 1.5mm |
| Open Way | A.Hand Button |
| B.Hand Rope | |
| C.Remote Control | |
| D.Radar Sensor | |
| E.Magnetic Sensor | |
| F.Photoelectric Sensor | |
| G.Linkage Lock | |
| Safe systems | |
| Photoelectric sensor |
installed on the side tracks, with emergency stopping reaction when sensing obstacles |
| Safe edge bottom |
when the people or vehicle touch the bottom edge of falling door,it bound up automatically |
| Emergency stop protection | with emergency stop button on control panel |
| Seal |
seal brush are Installed inside the guides, besides, there is trap heavier fabric on the bottom, close to any uneven ground |
| Technical parameter |
Power supply: single phase: 220V /three phase: 380 50Hz or TO YOUR ORDER |
| Power consumption: max 250W | |
| Opening & closing speed: 0.7-1.7m/s | |
| Opening & closing frequency: 1000-1500cycles/day | |
| Wind load: 20m/s | |
| Ambient temperature: -30°C to +50°C | |
