LED outdoor advertisement vehicle-EF-22

Mobile LED Display EF22-P10(foldable)

Chassis
Brand OMDM
External dimension(folded) 8030mm x 1600mm x 1800mm
Material 16 manganese steel
External dimension(unfolded) 8030mm x 3200mm x 1800mm
Tire Solid rubber tires
Total weight 5860kgs
Brake hydraulic braker(manual&impact)
Minimum turning diameter ≤16000mm

Hydraulic Lifting and Supporting System
Lifting System lift distance 2000mm, loading bearing 5000kgs
Hydraulic flip system flip&folding angle 180 degree
Hydraulic supporting system travel distance 300mm, wind-proof level 8 wind when screen lift up

LED Screen
Screen dimension 4800mm x 3200mm
Resoultion 192mm(W) x 192mm(H)
Chip brand R: Guanglei, G, B: Silan
Drive type 1∕4
Dot pitch 10 mm
Module resolution 16pixel(W) x 16pixel(H)
Color processing 10.7 billion
Pixel density 10000 dot/㎡
Brightness ≥6000cd/㎡
Viewing angle horizontal 110(+55/-55) degree
Max Power consumption 1200w/㎡
Average power consumption 600w/㎡
Brightness adjustment mode Software adjustment
Lifespan 100,000 hours

Power parameter
Input Voltage Three phases five wires 380V
Output Voltage 220V
Current 60A
Power consumption 0.5kwh/㎡

Multimedia Control System
Industrial PC Processor: Dual Core CPU, graphics card: 512, hard disk: 320G, CD-ROM: DVD
Monitor KVM 150inch LCD display, comes with keyboard and touch mouse
Speaker Max Power consumption: 200W
PA Unilateral power output: 200W

Optional configuration
Battery power&mechanical transmasssion is optional
