LED outdoor advertisement vehicle-EK-50II

Product parameters：

Mobile LED Display ES12-P10(E-K50II)(Scissor-Type)

Chassis
Brand OMDM
External 7160mm x 1820mm x 3455mm
Material 16 manganese steel
Total Weight 4750KGS
Minimum turning diameter ≤8000mm

Hydraulic Lifting and Supporting System
Hydraulic Lifting System Lifting Range 2000mm, bearing 5000kgs
Wind-proof System Level 8

LED Screen
Screen dimension 4800mm x 2400mm
Module Size 160mm(W) x 160mm(H)
Chip brand R: Guanglei, G﹑B: Silan
Dot pitch 10 mm
Brightness ≥6000cd/㎡
Max Power consumption 1200w/㎡
Average power consumption 600w/㎡
Lifespan 100,000 hours

Power parameter
Input Voltage Three phases five wires 380V
Output Voltage 220V
Current 50A
Power Average power consumption: 0.5kwh/㎡

Multimedia Control System
Industrial PC Processor: Dual Core CPU, graphics card: 512, hard disk: 320G, CD-ROM: DVD
Monitor 15-inch LCD Monitor
PA Unilateral power output: 200W
Speaker Max Power consumption: 200W
LED screen controlling system OMDM system
