Network Camera Module | TI 1.0mp 720P DM365/DM368+OV9712

Module parameters

HD-720P-38*38mm

1.0megapixel low-illumination HD web camera

Network Camera

• Sensor type 1/4 inch、1.0megapixel , CMOS low-illumination width dynamic sensor
• Minimum illumination Color: 1 Lux/F1.2, black and white: 0.02Lux/F1.2
• Electronic shutter 1/5 second ~ 1/50,000 second
• Lens port type C/CS port
• Automatic aperture DC driven
• Lens focal length 3.6mm, 6mm, 8mm, 12mm, 16mm, 25mm optional

Compression standards

• Video compression standards H.264 Main Profile Level 5.0
• Video compression rate 300Kbit/S~8Mbit/S
• Audio compression standards G .711


• Exposure mode Auto exposure, auto white balance, automatic tone-up
• Video resolution 1280×720(25fps) PAL，1280×720(30fps) NTSC
• Frame rate 1-30 frames/sec
• Playback frame rate 1280 x 720(25fps)PAL,1280 x 720(12.5fps)PAL,1280 x 720(30fps)NTSC,1280 x 720(15fps)NTSC
• Pixels width dynamic range 70DB
• Image setting Saturation, brightness, contrast adjustable via client terminal or IE browser

Web function

• Remote browse Support 320×192, 640×360 remote real-time browse and control
• Client management Offer multi-user hierarchical rights management, and allows multiple users to simultaneously access the equipment
• Remote reset and update Remotely reset system and update hardware via web
• Storage function Support SD card storage
• Intelligent alarm Mobile detection, video loss, cable breakage, IP address conflicts, full memory, memory fault, I/O alarm
• Support protocol RTSP、 TCP、UDP、IP、HTTP、FTP、SMTP、DHCP、DNS、ARP、ICMP、NTP
• Universal functions One key reset, anti-flicker, dual-stream, heartbeat, password protection, built-in watchdog

Port

• Audio input/output*1
• Communication port RJ45 10M/100M adaptive Ethernet port*1, RS-485 port*1
• Alarm input*1
• Alarm output*1
• D1 analog video output*1

General specifications

• Operating temperature and humidity -35℃~70℃, humidity< 90%(non-condensing)
• Power supply DC12V±10% / PoE
• IR-CUT voltage 12V
• Power consumption <2W</li>
• Size(mm) 38×38
• Weight 50g
• Photoresistance voltage 5V～12V
