New Type 1530 ATC 4 Axis CNC Router with Carousel Tool Changer Magazine
Prix : Negotiation
Features:
- Heavy duty frame and gantry.
- Carousel tool changer magazine,faster to change tools.
- Taiwan Syntec 21MA control system and servo motor driver system, famouse brand and good quality.
Parameters:
| Description | Parameters |
| Model | ELE1530-4A ATC |
| Working size | 1500*3000*400mm |
| Color | White and Blue (customizable) |
| Working Voltage | 220V, 3Phase, 60Hz |
| Control system | Taiwan Syntec 21MA control system with handle |
| Spindle | 9kw Italy HSD ATC air cooling spindle |
| Tool holder | ES951 |
| Inverter | 11kw Delta Inverter |
| Motor & Driver | 850W Yaskawa servo motors and 1kw Yaskawa drivers, Shimpo reducer |
| Auto tool changer magazine | Carousel |
| Tool slots | 8 |
| Table surface | T-slot and vacuum working table |
| Lubrication system | Automatic lubrication system |
| Gantry structure | Gantry moving |
| Structure | New type thicker and bigger heavy duty welded frame and gantry |
| Transmission | Helical Rack gear for X Y axis , Z Taiwan TBI ball screw for Zaxis |
| Rail | ABBA/PMI/HIWIN Linear square guide #25 |
| Vacuum pump | 7.5kw water circulation vacuum pump (220V, 3Phase, 60Hz) |
| Dust collector | 1.5kw new type double packet dust collector (220V, 3Phase, 60Hz) |
PS: All the working area and specifications can be customized according to your requests.
Personne à contacter : Jack Zhang, 86 0531 66564918
