Nylon conveyor belt

Fabric type

Fabric Structure

Fabric specs

Ply thickness

(mm/P)

(N/mm) Strength series

(mm)Cover thickness

Width mm

Length m

Warp

Weft

2ply

3ply

4 ply

5 ply

6 ply

Upper

Lower

Nylon (NN)

Nylon (N)

Nylon (N)

NN-100

0.70

200

300

400

500

600

1.5-8

0-4.5

400-2500

<=300</p>

NN-125

0.75

250

375

500

625

750

NN-150

0.80

300

450

600

750

900

NN-200

0.90

400

600

800

1000

1200

500-2500

NN-250

1.10

500

750

1000

1250

1500

NN-300

1.25

-

900

1200

1500

1800

NN-350

1.35

-

1050

1400

1750

2100

800-2500

NN-400

1.70

-

-

1600

2000

2400

NN-500

1.80

-

-

2000

2500

3000

Belt
carcass

Adhesive strength

Elongation

Between plies

N/mm

N/mm Between rubber and carcass

Longitudinal elongation at break

%>=

Longitudinal elongation at reference load

%<=</p>

Rubber thickness

<=1.5mm</p>

Rubber thickness

>1.5mm

Nylon canvas

>=4.50

>=3.2

>=3.5

10

4.0

Cover grade

Tensile strength
>=

Elongation
>=

Abrasion
<=</p>

Change Rate of tensile strength and elongation after aging

Mpa

kgf/cm²

%

mm 3

%

Heavy (H)

24

240

450

120

-25~+25

Medium (M)

18

180

400

100

-25~+25

Light (L)

15

150

350

200

-30~+30
