P4 Outdoor Mobile LED Advertising Trailers
DIP LED encapsulation confirm the high brightness even under strong sunlight Good protection level waterproof IP65, anti-corrosion, oxidation resistance, long life span Long viewing distance, High definition, Good uniformity Brightness can be adjusted automatically according to different surroundings. The mobile led advertising trailer Can be set to open and close the screen automatically. The mobile advertising trailers can be fixed on the wall, by pole support on the street, on top of building, or for stage rental hanging to meet the request of concert stage background, event show, live broadcasting, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, animation etc, connect with PC computer or network, also can remote control with asynchronous system, Wifi control, 3G control. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising etc.P6 P8 P10 type screen is optional. We can provide Dongfeng, Foton, FAW, JAC, JMC, SINOTRUK HOWO, or any other Chinese truck chassis brand. Quality mobile advertising trailers for sale.
The advantage of P6 Outdoor Mobile LED Advertising Trailer
1. High resolution and good best view distance;
2. Self contained whisper-quiet generator.
3. Standard waterproof cabinet which is IP65 and UV resistance;
4. Multi signal input.With Video Processor,signal can be PAL/NTSC,VGA ,Video ,DVD,TV etc.
5. Hydraulic system to support truck & trailer led display up and down;
6. LED Display brightness adjust automatically;
The specification of P6 Outdoor Mobile LED Advertising Trailer
|
CLW P6 LED TRAILER |
||
|
Item No. |
Parameters |
|
|
Dot Pixel |
P6 |
|
|
Display Size |
2 sets, 3840mm*1728mm |
|
|
Module Size |
192mm*192mm |
|
|
Pixel Configuration |
1R1G1B |
|
|
Module Resolution |
32*32(dots) |
|
|
Density |
27777dot/m2 |
|
|
LED Type |
SMD2727 |
|
|
Brightness |
≥5500CD/m2 |
|
|
Cabinet |
||
|
Cabinet Size（W*H） |
960mm*960mm |
|
|
Cabinet resolution |
160*160(dot) |
|
|
Viewing angle |
H: 140°/ V: 140° |
|
|
Protective Grade |
IP65 |
|
|
Average Power consumption |
550 Watt/cabinet |
|
|
Max Power consumption |
900 Watt/cabinet |
|
|
Best View distance |
6-80m |
|
|
|
≤ 55 kg/cabinet (Including |
|
|
Material |
Iron |
|
|
|
1. Power Modules |
|
|
2. Fans |
||
|
3. External Power cables & connectors |
||
|
4. Mounting/locking plates between cabinets |
||
|
5. Inter-connecting cables & ribbons (both power and signal) |
||
|
TRAILER PART |
|||
|
External Dimension |
7800mm×1800mm×2940mm |
||
|
Min turning radius |
>=16m |
||
|
Total weight |
5300kg |
||
|
Tire size |
16 inch |
||
|
Color |
Customized |
||
|
Wind resistant system |
Using hydraulic support led |
||
|
Hydraulic lifting |
Max 1.5m |
||
|
Rotation |
360° all around |
||
|
Electrical System |
|||
|
input voltage |
380V |
||
|
output voltage |
220V |
||
|
electricity |
50A |
||
|
average power consumption |
0.5wh/㎡ |
||
|
|
16kw |
||
|
Multimedia System |
|
|
power amplifier |
200W |
|
speakers |
200W |
|
video processor |
can support USB/DVD/HDMI/DVI/VGA |
|
surface paint |
Customized |
|
brake |
hydraulic brake |
|
metal plate structure |
cold rolled board |
|
Control system and LED |
|
|
Adopted Control System |
PCTV Board + DVI Board + Control Board + Network cable Transmission |
|
Video Signal |
RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION etc |
|
LED parameter |
R: (620-623nm) G: (519-522nm) B: (466-467 nm) |
|
Brightness Level |
Manual adjustment: 256 levels for R, G, B |
