PA66 GF20 (A2000D)
Reinforced with 20% of glass fiber on substrate PA66 is called PA66 GF20, it improves dimensionally stabilized and impact resistance for injection moulding.
Typical Application of PA66 GF 20 (A2000D)
PA GF20 is applied to various precision gears due to its high rigidity, dimensional stability, noise reduction, wear resistance, quietness, lubrication and antistatic.
Processing Detail of PA66 GF20 (A2000D)
Other Details of PA66 GF20 (A2000D)
Physical Property
|
Ash |
(20.0% 1 ISO3451/1) |
|
Conditioned |
600°C*2h |
|
Density |
(1285Kg/m3 1 ISO1183) |
|
Conditioned |
23°C |
|
Shrinkage Parallel Flow |
(0.5-0.9 % 1 ISO294-4) |
|
Shrinkage Vertical Flow |
(0.8-1.1% I ISO294-4) |
Mechanical Properties
|
Tensile strength (145.0MPa 1 ISO527) Conditioned |
5mm/ min |
|
Tensile Strain at Break (2.5% I ISO527) Conditioned |
5mm/min |
|
Notched Impact Strength (8.5KJ/m2 I ISO179) Conditioned |
1.0J |
|
Flexural Strength (235MPa 1ISO178) Conditioned |
2mm/min |
|
Flexural Modulus (6876 MPa I ISO178) Conditioned |
2mm/ min |
Thermal Property
|
Melting Point |
(260°C I ISO11357) |
|
Hot Deformation Temperature |
(245*C I ISO75) |
|
Conditioned |
1.8MPa |
|
Flammability Class |
(HB 1UL94) |
|
Conditioned |
mm |
Injection Molding Conditions
|
Drying Temperature |
130°C |
|
Drying Time |
3h |
|
Cylinder Temperature |
280-300°C |
|
Nozzle Temperature |
280-300*C |
|
Tooling Temperature |
80-100*C |
* Molding conditions are just for reference, please make an adjustment based on the actual situation！
Want to know the details of modified polyethylene or buy pa6 6 gf50, contact us.
