Patchcord LC-FC MM Duplex 3.0mm PVC
Quantité : 2500km/wee Prix : < 200 USD
Description:
UnitekFiber provide patch cords. Path chord means that the terminations are connect at both ends of the optical cable to realize the optical path active connection.
Patchcord LC-FC MM Duplex 3.0mm PVCPatchcord-LC-FC-MM-Duplex-3.0mm-PVC-2.jpg Patch cord LC-FC MM Duplex 3.0mm PVC
Optical Fiber lc to fc patch cord is similar to coaxial cable except that there is no mesh shield. The light-transmitting glass core is in the central. The fiber core has a diameter of 50/125μm to 65/125μm for multi mode fiber path cords, which is roughly equivalent to the thickness of a human hair. The diameter for single mode fiber core is 8μm to 10μm. The fiber core is wrapped by a glass which is having a lower index of refraction than the core to maintain the fiber within the core.
Characteristics:
Using high precision ceramic ferrule
Low insertion loss and high return loss
Excellent stability and high repetition
100% Optic test (Insertion Loss & Return Loss)
Application:
Telecommunication Network
Fiber Broad Band Network
CATV system
LAN and WAN system
FTTP
Specification
Parameter |
Unit |
Mode Type |
PC |
UPC |
APC |
Insertion Loss |
dB |
SM |
≤0.3 |
≤0.3 |
≤0.3 |
MM |
≤0.3 |
≤0.3 |
----- |
||
Return Loss |
dB |
SM |
≥50 |
≥50 |
≥60 |
MM |
≥35 |
≥35 |
----- |
||
Repeatability |
dB |
Additional loss<0.1db,return loss< 5 dB</span> |
|||
Interchangeability |
dB |
Additional loss<0.1db,return loss< 5 dB</span> |
|||
Connection times |
times |
>1000 |
|||
Operating Temperature |
℃ |
-40℃- +75℃ |
|||
Storage Temperature |
℃ |
-40℃- +85℃ |
