PCD, PCBN, CVD, tungsten, carbide tools grinding machine

grinding machine

PCD, PCBN, CVD, tungsten, carbide tools grinding machine
1.Main Technical Parameters
1-1.Spindle and Grinding Wheel
1)Diameter of Grinding wheel: 150mm
2)Direct Drive Spindle with Water Cooling: 3KW
3)RPM of Grinding Spindle: 0~3,000RPM
4)Changeable Clearance Angle: -5°~25°
5)Grinding wheel center hole: 40mm
6)Spindle Center Height: 150mm
1-2.Grinding Wheel Oscillation System(X Axis)
1)PLC Numerical Controlled Oscillation and Control on the Panel
2)Max. Oscillation Range: 30mm
3)Max. Oscillation Frequency: 60times/minute
1-3.CCD Monitoring System
1)Max Magnification of Optical Microscope: 4 times
2)Magnification of CCD Measuring System : 80times
3)19Industrial Displayer: 19"
4)CCD Image Resolution: 1280*1024
1-4.Feed and Rotation System
1)Compressor of Air Braking on Rotation Axis: 6bar
2)Tool rotation (B axis) controlled by PLC. Can be switched to manual mode: LCD input
3)Horizontal Transverse (Y Axis) Driven by Air: 70mm
4)Linear Encoder Resolution (X Axis and Y Axis): 0.001mm
1-5.Power Supply and Dimensions
1)Coolant Tank with Filter Paper: about70L
2)Electrical Supply: 12Kw
3)Voltage Requested: 380V/Three phase /50Hz
4)Overall Dimensions L-W-H: 1700-1150-1970mm
5)Weight With Coolant Tank: 2000Kg
2.Packing: wooden case
3.Offer validity : 3 months
4.Port: Tianjin,Qingdao
5.Payment terms: 100% Payment before delivery.
6. Delivery time: 45 work days after sign contract, if any special requirement can be consulted
7.Contact person: Nina Qiao skype: nina-superhardtools

Localisation : skype:nina-superhardtools, 450001 Zhengzhou,
Personne à contacter : Nina Qiao, 8615738374568
