Photovoltaic 1000 DC Power SPD
Quantité : 1 million Prix : 200-2000 CNY/pc
Photovoltaic SPD for DC power, 1000VDC; In(8/20us): 20kA/phase, Imax: 40kA/phase; hot-pluggable; fault indication;
Features & Advantages of Photovoltaic SPD 1000VDC
Status indication:
Green: OK
Red: Failed
DC power surge protector modules can be replaced online.
Remote alarm output is optional, named with "F".
It is normally installed at the boundary of LPZ1 and LPZ2 or subsequent LPZs.
Parameter of Photovoltaic 1000V DC SPD
|
|
|
|
T2-1000 |
|
|
T2-1000F |
|
|
Max. continuous operating voltage Ucpv |
1000VDC |
|
Short-circuit current rating Iscpv |
1000A |
|
Nominal discharge current In(8/20µs) |
20kA |
|
Max. discharge current Imax(8/20µs) |
40kA |
|
Voltage protection level Up |
4kV |
|
Recommended backup fuse |
80A gG |
|
Recommended grounding cable |
6~35mm2 |
|
Response time |
25ns |
|
Residual current IPE |
<10μA</p> |
|
Remote alarm output |
250VAC/0.5A;24VDC/0.5A |
|
Housing protection grade(IEC60529) |
IP 20 |
|
Housing material/inflammability rating(UL94) |
PA66/V0 |
|
Testing standard |
IEC 61643-31 |
CHENZHU strives to provide high-quality products and services to meet the expectations of our customers and interested parties by delivering outstanding performance. We have special talents to research and develop safety and automation system. Indeed, automation and safety are our interface products' main characters.
