PN Series Passive Speaker Box

PN Series Passive Speaker Box

PN08

PN08 Speaker Box Discription: 8" 2 Way Passiver Speaker

PN08 Speaker Box Freq Response: 40 Hz-19 KHz

PN08 Speaker Box Max SPL: 92dB

PN08 Speaker Box Sensitivity: 90 dB± 2dB

PN08 Speaker Box Impedance: 8 Ω

PN08 Speaker Box Low Freq Woofer: 8" 30oz 1.5" VC

PN08 Speaker Box High Freq Driver: 1" Ti. Diap. Driver 8 Ω

PN08 Speaker Box Rms Power: 90 W

PN08 Speaker Box Package(W×D×H): 295×245×435 mm

PN08 Speaker Box Weight: 7 kgs

PN10

PN10 Speaker Box Discription: 10" 2Way Passiver Speaker

PN10 Speaker Box Freq Response: 30 Hz-19 KHz

PN10 Speaker Box Max SPL: 95dB

PN10 Speaker Box Sensitivity: 93 dB± 2dB

PN10 Speaker Box Impedance: 8 Ω

PN10 Speaker Box Low Freq Woofer: 10" 30oz 1.5" VC

PN10 Speaker Box High Freq Driver: 1" Ti. Diap. Driver 8 Ω

PN10 Speaker Box Rms Power: 120 W

PN10 Speaker Box Package(W×D×H): 355×295×545 mm

PN10 Speaker Box Weight: 10 kgs

PN12

PN12 Speaker Box Discription: 12" 2Way Passiver Speaker

PN12 Speaker Box Freq Response: 30 Hz-20 KHz

PN12 Speaker Box Max SPL: 98dB

PN12 Speaker Box Sensitivity: 97 dB± 2dB

PN12 Speaker Box Impedance: 8 Ω

PN12 Speaker Box Low Freq Woofer: 12" 40oz 2" VC

PN12 Speaker Box High Freq Driver: 1.35" Ti. Diap. Driver 8 Ω

PN12 Speaker Box Rms Power: 140 W

PN12 Speaker Box Package(W×D×H): 420×341×628 mm

PN12 Speaker Box Weight: 13 kgs

PN15

PN15 Speaker Box Discription: 15" 2Way Passiver Speaker

PN15 Speaker Box Freq Response: 30 Hz-20 KHz

PN15 Speaker Box Max SPL: 100dB

PN15 Speaker Box Sensitivity: 98 dB± 2dB

PN15 Speaker Box Impedance: 8 Ω

PN15 Speaker Box Low Freq Woofer: 15" 50oz 2.5" VC

PN15 Speaker Box High Freq Driver: 1.35" Ti. Diap. Driver 8 Ω

PN15 Speaker Box Rms Power: 180 W

PN15 Speaker Box Package(W×D×H): 485×400×740 mm

PN15 Speaker Box Weight: 16 kgs
