Protective suspension type high voltage cable clamp
Quantité : MOQ 1000 P Prix : 1-3 usd
Products adopt high strength anti-corrosion alloy materials, used for suspension cable fixed, it han gs clevis with tensioning wire connection, reasonable clamp structure, convenient installation, doe s not damage the cable.
1. The cable with rubber mat, clamp placed in the body;
2. Use bolt to fasten on the clamp body cable;
3. Place two pieces of the lower boom puckering on the lateral bolt clamp body, and should be split pin locks in the boom of the lateral, in case the boom out;
4.The boom under the above side two holes with bolt connection;
5. Place the clevis on the steel wire rope, clamp components good assembled and
clevis with bolt connection.
|
Model No. |
Applicable outside diameter of cable
|
中 |
H |
B |
|
JGX-1 |
φ50-φ60 |
6O |
280 |
5O |
|
JGX-2 |
φ60-φ70 |
7O |
290 |
5O |
|
JGX-3 |
φ70-φ80 |
8O |
306 |
6O |
|
JGX-4 |
φ80-φ90 |
9O |
320 |
6O |
|
JGX-5 |
φ90-φ100 |
100 |
336 |
60 |
Personne à contacter : Monica Lee, 86 15931620963
