RTC6122W WLP IR Fire Detector
Quantité : 5-2000 uni Prix : $269-$2000 (conventi
RTC6122W IR Fire Detector
RTC6122W WLP Packaged Uncooled Infrared Detector employs a self-developed 12μm uncooled VOx thermal imaging ir fire sensor capable of 640×512 resolution. Available in a WLP package, the RTC6122W infrared detector is suitable for micro-module applications with features such as affordability, low power consumption, compactness, lightweight, and long service life.
Resolution: 640×512
Pixel size: 12μm
Features of RTC6122W WLP IR Fire Detector
1. VOx microbolometer
2. Low power consumption: <170mW</p>
3. Package weight: <0.5g</p>
4. High sensitivity: NETD<50mK</p>
5. Thermal time constant: <10ms</p>
6. WLP package
Applications of RTC6122W WLP IR Fire Detector
Specifications of RTC6122W WLP IR Fire Detector
|
Item |
Specifications |
|
Model |
RTC6122W |
|
Sensor Technology |
VOx microbolometer |
|
Spectral Range |
LWIR, 8-14μm |
|
Pixel Pitch |
12μm |
|
Array Format |
640×512 |
|
Operability |
≥99.5% |
|
NETD |
<50mK (@f/1.0,50Hz,300K)</p> |
|
Thermal Time Constant |
<10ms</p> |
|
Frame Rate |
≤60Hz |
|
Power Consumption |
<170mW (@50Hz, 300K)</p> |
|
Output Format |
14bits |
|
Wide Dynamic Range Mode |
Support -40~600ºC temperature measurement (@f/1.0) |
|
Read Mode: rolling Shutter Mode |
Line-by-line |
|
Mirroring |
X and Y directions |
|
Non-uniformity Correction |
On-chip 6-bit non-uniformity correction |
|
Operating Temperature Range |
-40°C~+85°C |
|
Package Type |
WLP vacuum package |
|
Size |
12.82×12.085×1.55mm³ (without pin) |
|
Weight |
<0.5g</p> |
If you want to find a reliable thermal scanner manufacturer, please contact us, and we will be your best partner.
